- Page 1 AIR COOLER OWNER’S MANUAL Air Cooler MODEL:AC120-19ARB GD Midea Environment Appliances MFG.Co.,Ltd. READ AND SAVE THESE INSTRUCTIONS No.28, Dong Fu Road, Hesui East Industrial Area, Dong Feng Town, Attention: Pictures in the IM are for reference only. Zhongshan, Guangdong 528425 P.R.China...
-
Page 2: Rules For Safe Operation
CAUTION Read Rules for Safe Operation and Instructions Carefully. WARNING 1. If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid. -
Page 3: Product Profile
Product Profile Note The pictures contained in the Manual are for reference only, and it is subject to the physical product in the packing box. Name of components Control part Wetted pad Ice crystal box The ice crystal box Reel is a random gift Water tank... - Page 4 Operating Manual Water adding in water tank and instructions for disassembly and washing Note • Please clear the water collected at the bottom of the water tank when the machine is idle. • When adding water and cleaning, the power plug should be unplugged. •...
- Page 5 5 After use, the water tank should be pushed, the water pump module should be fixed, and then the water tank buckle should be locked to lock the water tank Use of Ice Crystal Box Note ① The ice crystal box can be repeatedly frozen and recycled; It can also not be used depending on the temperature. ②...
-
Page 6: Circuit Diagram
Operating Manual for Machine Body Machine body key Display panel Function description Product start or stop. Touch the swinging wind key to start or stop swinging wind. Short press in the start state to start or stop humidification. In the dry or hot weather, start the humidification function to have a better experience. - Page 7 Note Instructions of remote controller buttons ・ The remote controller can be used normally within the scope of 5 meters and 30 degrees of the deviation angle in front of the product. ・ The battery contains many heavy metals, acid-base and other materials, being a threat to human health;...
-
Page 8: Maintenance Instruction
MAINTENANCE INSTRUCTION The fan requires little maintenance. Do not try to fix it by yourself. Refer it to qualified service personnel if service is needed. 1. Before cleaning and assembling, fan must be unplugged. 2. To ensure adequate air circulation to the motor, keep vents at the rear of the motor free of dust.
