- Page 1 ELECTRIC FAN OWNER’S MANUAL AIR COOLER MODEL:AC200-17JR READ AND SAVE THESE INSTRUCTIONS GD Midea Environment Appliances MFG.Co.,Ltd. Attention: Pictures in the IM are for reference only. No.28, Dong Fu Road, Hesui East Industrial Area, Dong Feng Town, Zhongshan, Guangdong 528425 P.R.China...
-
Page 2: Safety Instruction
SAFETY INSTRUCTION 1. If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2. Household Indoor use only. 3. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervisionor instruction concerning use of the appliance by a... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Name of components Installation of the water tank: Control panel Air outlet Water tank fastener Take out the water tank cover from the Ice box fan body Water window Water tank Wheel Fix the cover on the water tank Foot-Wheel Installation Front Foot-wheel... -
Page 4: Battery Installation
INSTRUCTIONS FOR USE Instructions for key of remote controller Battery Installation Pull Notch Locking latch Considerate Hint: 1. Effective Range of Remote Control: within 5m distance and 30-degree deflection in front of Product. - Page 5 Instructions for operation of body Press a key on the unit to activate a corresponding function. For instance: ● Press [OSC.] Key to activate or deactivate Swing Function. (Note: Manual horizontal blade allows tilting flow direction.) ● Press [SPEED] Key to adjust 3 speeds of air flow. ●...
- Page 6 ADD WATER Add water from top: Rotate water tank's top cover, fill in water. Add water from side: Rotate water tank's side cover, fill in water. fill water from top filter frame water tank fill water from bottom water tank Ice box Put the ice box into water tank...
-
Page 7: Troubleshooting
TROUBLESHOOTING In case the product cannot be operated normally after installation, checks shall be made for items described bellow: 1. Power cable unplugged or faulty contact. 2. Honeycomb filter assembly not properly installed. 3. Power Switch on the back of product or in the display panel not switched If product remains dysfunctional after checking, a local dealer shall be sought for assistance.
