ASSEMBLY INSTRUCTIONS
Thank you for purchasing this product.Please take time to read and follow the instructions below. Check that you have all
parts and hardware before assembly. Parts apparently missing are often found in the packing materials. If you do not
have all the parts listed, have your dealer contact us and they will be sent to you immediately.
It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing
furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet.
PARTS LIST LISTE DE PIECES
NO.
Description
A
DRESSER
B
LEG
C
SUPPORTS LEG
D
MIRROR
E
MIRROR SUPPORTS

STEP 1

** DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED /
SOIT COMPLETMENT TERMINE.
TAKE OUT THE BUN FOOT FROM
BOTTOM DRAWER FOR ASSEMBLY.
1615-5 DRESSER / COMMODE &
ITEM NO:
1615-6
MIRROR / MIROIR
Sketch
Q'ty
1PC
4PCS
1PC
1PC
2PCS
HARDWARE LIST LISTE DE QUINCAILLERIE
NO.
Description
BOLT
1
SPRING WASHER
2
3
FLAT WASHER
ALLEN KEY
4
Tipping restraint
5
**ABOVE HARDWARE ARE PACKED IN 1615-5 FOR ASSEMBLY
BOLT
6
SPRING WASHER
7
8
FLAT WASHER
ALLEN KEY
9
**ABOVE HARDWARE ARE PACKED IN 1615-6 FOR ASSEMBLY

STEP 2

B
B
1 OF 2
Sketch
Q'ty
Size
5/16''x57mm
8PCS
8PCS
5/16''x12x2mm
8PCS
5/16''x19x2mm
1PC
5x 58mm
1SET
1/4''x38mm
8PCS
8PCS
1/4''x12x2mm
8PCS
1/4''x19x2mm
1PC
4x58mm
C
