Steelcraft LA-2231-00G Quick Start Manual

4 1/2"O.D. PORTABLE PRACTICE ROUND SOCCER GOALS
8' H x 24' W
#LA-2231-00G STEEL - WITH END FRAMES - 8'H x 24'W (1,190 LBS) PER SET
#LA-2231-00A ALUMINUM - WITH END FRAMES - 8'H x 24'W (602 LBS) PER SET
SPECIFICATIONS:
NCAA soccer goal which provides a 8'H x 24'W front inside opening.
Crossbar and Uprights - a single length of 4 1/2" O.D. steel or aluminum tubing, powder coated white.
Crossbar is bolted to uprights.
All hardware is zinc-plated or Stainless Steel for long, rust free service.
Warranty period: 10 years
`
INSTALLATION:
1. Lay Upright/Corner Assemblies 24' apart parallel to each other on the ground with drilled pipe stubs
facing up
2. Assemble crossbar to upright/corner assemblies with 3/8"-16 x 4" Button Head Bolts and Barrel
nuts.
3. Sleeve a T-fitting onto the bottom leg of net support. Make sure set
4. Insert net supports over 2" O.D. drilled inner sleeve stubs on corner assembly units
5. Align holes provided and attach with 3/8" x 3" hex head bolts
6. Attach spreader pipe between net supports. Insert spreader pipe into T-fittings and align holes,
bolt through with 3/8" x 3-1/2" hex head bolts and tighten. NOTE: Position spreader pipe as far
back on long leg as possible and tighten 3/8" set screws with hex key
7. Tighten all bolts and set screws, cut and peen any excess threads
8. Carefully rotate goal into upright position. Repeat steps for other goal
9.
*OPTIONAL TRANSPORT ASSEMBLY*
Bolt Adjustable Wheel Bracket & Pnuematic Wheels in drilled hole locations
ANCHORING SYSTEM (AUGER ANCHOR)
1. Connect chain to portable goal. Connect opposite end to auger. Pull chain tight then stick auger in
ground surface at an slight angle away from goal. (See Page 5, Auger Picture) Twist auger all the way in-
ground so the top hook/chain are slightly exposed.
PRODUCT NAME
Date: 7/26/2017
Rev: A
Drawn: BDYE
MODEL NO.
Sheet: 1 of 5
screws will face up.
SOCCER GOAL
SPEC LA-2231-00A-00G
