Summary of Contents for Steelcraft LA-810-JH-4S
- Page 1 SHEET LA-810-JH-4S PORTABLE 1 OF 2 BASEBALLBACKSTOP NOTE: SPECIFICATIONS ARE SUBJECT TO CHANGE DATE: 2/7/12 DRAWN BY: AFS DO NOT SCALE DRAWING...
- Page 2 SHEET LA-810-JH-4S PORTABLE 2 OF 2 BASEBALLBACKSTOP CORNER SUPPORT WITHOUT OPTIONAL WHEEL ASSEMBLY 8'-6" 10'-2 1/2" 20'-6" PLAN VIEW 10'-2 1/2" FRONT VIEW ASSEMBLY INSTRUCTIONS 1. Assemble the two skids (E) on the ground to form a right angle. Slide the 3 way fittings (G)on each skid pipe.
