ROBOTICS
TXT 4.0 CONTROLLER

MASTER OR EXTENSION

This symbol indicates whether the Controller is set at the Master or Extension.
M = operated as the Master (LED of the ON/OFF button illuminated blue); E = operated as Extension (LED of the
ON/OFF button illuminated green).
Changes can be made in the
Master:
The Controller set as the master receives control commands directly from the PC and transmits them to the
extensions.
Extension:
The Controller set as the extension receives control commands only from the master.
Up to 9 extensions are possible.
Single:
In this mode, using the CAN interface to connect additional TXT 4.0 Controllers as expansions is not supported.
This results in an energy savings of up to 10%, and therefore a longer battery life.

TIME

Displays the current set time. This can be changed using the

CONTROL ELEMENTS

The user can navigate through the menu by touching the control elements.
One step back
in menu
© Copyright 2001-2021 fischertechnik GmbH | Klaus-Fischer-Straße 1 | 72178 Waldachtal
fischertechnik TXT Operating manual_EN | 10. November 2021, 9:18 PM
Settings | Properties menu.
Scroll/swipe
To scroll through longer menus (appears only if the menu requires).
Back to main menu
Settings| Date and time menu.
