Specifications - Extron electronics IPL T S Specification Sheet

sPeciFications

EthErnEt control intErfacE
Connectors ..................................... 1 RJ-45 female connector
Data rate ......................................... 10/100Base-T, half/full duplex with
Protocols ......................................... ARP, DHCP, ICMP (ping), TCP/IP, UDP/
Default settings ............................... Link speed and duplex level =
Web server
IPL T S1 ........................................ Up to 200 simultaneous sessions
All other models ........................... Up to 200 simultaneous sessions
Program control .............................. Extron's Simple Instruction Set (SIS
Global Viewer requirements ............ Microsoft
SErial control intErfacE
Quantity/type
IPL T S1 ........................................ 1 RS-232-only
IPL T S2 ........................................ 2 RS-232/RS-422/RS-485 configurable
IPL T S4 ........................................ 4 RS-232/RS-422/RS-485 configurable
IPL T S6 ........................................ 2 RS-232/RS-422/RS-485 configurable
Connectors
IPL T S1 ........................................ (1) 9-pin male D
IPL T S2 ........................................ (2) 9-pin male D and (1) 3.5 mm
IPL T S4 ........................................ (4) 9-pin male D
IPL T S6 ........................................ (2) 9-pin male D and (1) 3.5 mm
Baud rate and protocol ................... 300 to 115200 baud
Pin configurations
Serial, 9-pin D (IPL T S1)
RS 232 ...................................... 2 = RX, 3 = TX, 5 = GND, 7 = RTS,
Serial, 9-pin D (IPL T S2, IPL T S4)
RS 232 (default) ......................... 2 = RX, 3 = TX, 5 = GND, 7 = RTS,
RS 422 ....................................... 2 = RX-, 3 = TX-, 5 = GND, 7 = TX+,
RS 485 ....................................... 2&3 (tied together) = data-,
Serial, 5-pole captive screw (IPL T S2)
Serial, 10-pole captive screw (IPL T S6)
autodetect
IP, Telnet, HTTP, SMTP
autodetected
IP address = 192.168.254.254
Subnet mask = 255.255.0.0
Gateway = 0.0.0.0
DHCP = off
1.25 MB nonvolatile user memory
7.25 MB nonvolatile user memory
™
Internet Explorer ver. 6 or
®
higher
serial
serial
serial
4 RS-232-only
captive screw connector, 5 pole
captive screw connector, 10 pole
Default settings (adjustable): 9600
baud, 8 data bits, 1 stop bit, no parity
8 = CTS
8 = CTS
8 = RX+
5 = GND, 7&8 (tied together) = data+
COM1: pin 1 = TX, 2 = RX, 3 = GND
COM2: pin 4 = TX, 5 = RX, 3 = GND
COM3: pin 1 = TX, 2 = RX, 3 = GND
COM4: pin 4 = TX, 5 = RX, 3 = GND
COM5: pin 6 = TX, 7 = RX, 8 = GND
COM6: pin 9 = TX, 10 = RX, 8 = GND
GEnEral
Power ............................................ Supplied by an included external
External power supply ..................... 100 VAC to 240 VAC, 50/60 Hz,
Power input requirements ............... 12 VDC, 0.5 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to
Rack mount ..................................... Yes, with optional 1U rack shelf, part
)
Enclosure type ................................. Metal
Enclosure dimensions
IPL T S1 ........................................... 1.0" H x 4.3" W x 3.0" D (1U high,
All other models .............................. 1.7" H x 4.3" W x 3.0" D (1U high,
Product weight ............................... 0.7 lbs (0.3 kg)
Shipping weight ............................. 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe
Listings ............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
Model Version Description
IPL T S1 One Serial Port ........................................... 60-801-01
IPL T S2 Two Serial Ports .......................................... 60-544-81
IPL T S4 Four Serial Ports .......................................... 60-544-83
IPL T S6 Six Serial Ports ............................................ 60-544-84
Optional Accessories
RSF 123 Rack Shelf Kit .............................................. 60-190-20
RSU 129 Universal Rack Shelf Kit ............................... 60-190-01
MBU 125 Under-Desk Mount Kit ................................ 70-077-01
PMK 100 Mini Projector Mount Kit ............................ 70-217-01
Specifications are subject to change without notice.
power supply.
external, autoswitchable; to 12 VDC,
1 A, regulated
+70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to
+50 °C) / 10% to 90%, noncondensing
#60-190-01, or the VersaTools rack
®
shelf, part #60-190-20; also under-
furniture mountable with optional
brackets #70-212-01or projector
mountable with optional brackets
#70-217-01/70-077-04
quarter rack wide) 2.5 cm H x
10.9 cm W x 7.6 cm D (Depth
excludes connectors.)
quarter rack wide) 4.3 cm H x
10.9 cm W x 7.6 cm D
(Depth excludes connectors.)
Transit Association)
Part Number
