CGHE1 Installation
& Operating Guide

Components

When you purchase the Everpure
Grade Instant Hot Water tank, contents include:
quick-connect
fitting
quick-connect fitting
with filter and cap
Materials required (not provided)
2 mounting bracket screws
(and 2 plastic anchors if
attaching to drywall)
Shut-Off valve
with "T" fitting
(EV312120)
(Connections must meet all local codes and ordinances.)
Tools and Safety Equipment you may need (not provided)
• ruler or measuring tape
• pliers
• hand or electric drill
• small drill bit for starter holes
Faucet Compatibility
Only "Open Vent" faucets function with a instant hot water dispenser tank.
Connecting a standard faucet will damage the tank and void the warranty.
IMPORTANT INFORMATION
This hot water dispenser produces instant hot water of approximately 190°F (88°C) as dispensed
from the faucet.
This product is not intended to produce a continuous flow of hot water. The standard model will
produce up to 60 cups of water per hour at approximately 190°F (88°C). Due to high water
temperature, for safety reasons, the tank is not under pressure. Consequently, there is a slight
delay of water flow after the faucet has been activated. This is normal and indicates that the
expansion chamber is functioning properly.
®
Commerical
tank mounting
bracket
1
/
" (6.4 mm)
4
O.D. copper
tubing.
3
• 1
/
" drill bit - if no sink
8
hole exists
• safety glasses
• bucket or pan
tank
• open-end wrench(es)
• gloves
• tubing cutter
560H486P01 REV E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGHE1 and is the answer not in the manual?

Questions and answers

Related Manuals for Everpure CGHE1

Summary of Contents for Everpure CGHE1

  • Page 1: Important Information

    Connecting a standard faucet will damage the tank and void the warranty. IMPORTANT INFORMATION This hot water dispenser produces instant hot water of approximately 190°F (88°C) as dispensed from the faucet. This product is not intended to produce a continuous flow of hot water. The standard model will produce up to 60 cups of water per hour at approximately 190°F (88°C).

  • Page 2: Important Safety Instructions

    ELECTRICAL REQUIREMENTS Recommended Ground Method For your personal safety, the hot water dispenser is equipped with a power supply cord having a 3-prong ground plug. To minimize possible shock hazard, the cord must be plugged into a mating 3-prong, ground-type outlet, grounded in accordance with the National Electrical Code, ANSI/NFPA 70 —...
  • Page 3 For a hot water dispenser, the faucet valve is placed before the tank, creating an “open vent” style faucet and consequently no pressure is built up inside the tank.

  • Page 4: Before You Begin

    INSTALLATION Before You Begin Determine where you will install your hot water dispenser. The faucet can be mounted in an existing hole in the sink (spray hose, etc.), or drill a 1 use the spray unit or do not have a hole in your sink you will have to drill a new hole.
  • Page 5 The cap end of the fitting connects to the faucet line. Make sure the cold water connecting to the faucet is filtered. Use an Everpure Commerical Grade Filter System to provide filtered water. Refer to the Everpure Filter System Install and Operation Manual for installation procedures.
  • Page 6 Step 5 - Check for Leaks Open valve in water line. Turn faucet on (hold if necessary) to fill tank (about 1 minute). When tank is full, water will flow from faucet. Turn faucet off. Check for leaks. Step 6 - Prepare for Power Double check thermostat control dial is in the OFF position.

  • Page 7: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Seasonal Shutdown To prevent damage when dispenser is exposed to freezing temperatures, water must be drained. 1. Unplug dispenser tank to power supply. 2. Turn thermostat control dial to OFF position (fully counterclockwise). 3. Turn faucet on and run water until water is cold. 4.

  • Page 8: Troubleshooting

    • Lower temperature setting by turning thermostat control dial counterclockwise. NOTE: If lowering the thermostat setting does not stop the boiling, unplug the power supply cord and contact customer service. 1040 Murifield Drive • Hanover Park, IL 60133 USA Toll Free: 800-323-7873 • Technical Service: 800-942-1153 Everpure, LLC www.everpure.com...
