Thank you very much for purchasing PIAA product. Please read this instruction
manual thoroughly for proper use of the product. After completing your
installation, keep this manual for future reference.
※ The and marks indicated in this manual are
cautionary points related to the installation of the product.
To ensure safe and secure installation of the product, please follow these points closely.
To user
To shop owners installing the product
Please read the cautionary points before installation to ensure safe utilization of the product.
● The lamp becomes very hot when turned on. When parking your car near fl ammable items such as dried leaves, turn off the
lamp as it may cause a fi re.
● Do not look directly into the light for long periods. Doing so may cause eye irritation or visual impairment.
● The lamp and the switch harness are intended for motorized vehicle use only. Do not use for any other purpose.
● This lamp is intended for use in rain (day or night), during foggy or snowy conditions where visibility is hampered.
Do not use during normal driving conditions.
● Do not operate the switch while driving, unless local laws allow you to do so.
● If the lamp is kept on when the engine is not running, it will drain the battery.
● Make sure the lamp is installed securely before driving the vehicle. If a problem is found, fi x it immediately.
● Check for any loose screws that hold the lamp in place before driving. If you fi nd any loose screws or bolts (if a bracket is
used), tighten them securely. If you notice a loose part while driving, inspect the section immediately and make the necessary
adjustments.
● Avoid repeatedly turning the lamp off and on as it may reduce the overall life of the LED.
● Some vehicles produce a high voltage electric charge when the engine is started. Avoid loading extra voltage to lamps by
turning the switch off when you start engine.
● Avoid needless disassembly of the lamp or the switch harness as it may cause it to fail.
● If the lamp and/or the switch harness is removed and set aside for safekeeping, wipe away all dust or grime and store in a
place free of moisture.
● If the lens is cracked or damaged in any way, verify whether there is any damage to the harness. If there is any damage to
the cord covering, replace it immediately.
● Avoid injury when replacing the harness and the switch Please dispose of it as a non-combustible item.
RF6 ／ RF10 ／ RF18
Installation Instructions
... Please keep this manual and a receipt with the name of the shop
where you bought it.
When giving this product to a third party, always include this manual
together with the product.
... After installation of the product, make sure the customer is provided
with this owner
-1-
s manual.
'
PKI-0041-5-E
Advertisement
Table of Contents
Related Manuals for Piaa RF6
Summary of Contents for Piaa RF6
- Page 1 PKI-0041-5-E RF6 ／ RF10 ／ RF18 Installation Instructions Thank you very much for purchasing PIAA product. Please read this instruction manual thoroughly for proper use of the product. After completing your installation, keep this manual for future reference. ※ The and marks indicated in this manual are ...
- Page 2 PKI-0041-5-E Please read the installation procedures thoroughly beforehand. ● In order for the lamp to perform at its full potential, use the relay harnesses manufactured by PIAA. ● All work procedures should be carried out in a location with adequate space. Place the shift lever in the parking position. Turn off the engine and set the parking brake. ● Make sure the engine compartment is adequately cool before starting work. Do not begin work if engine parts such as radiator, oil-cooler or turbo parts are still hot. ● Do not add additional holes to the main body of the lamp. Also, do not apply adhesives or stickers to the lamp parts. ● Do not modify the lamp harness or the switch harness in any way. Such modifi cations may cause it to overheat or short. In some cases, it may cause the vehicle to catch fi re. PIAA will not be liable for damage caused by such modifi cations. ● When removing the battery terminals, do not touch the (-) and (+) terminals simultaneously. An electrical shock may occur. Wear rubber gloves when carrying out such work procedures. ● Make sure the (-) and (+) terminals do not make contact with metal. It can be extremely dangerous if a short occurs. ● Make sure all bolts are tightly secure. If there are any loose bolts tighten them accordingly. ● After installing the lamp, adjust the lamp so the beam shines at least 40m in front of the vehicle. Also, adjust the lamp a little toward the right so that it does not shine directly into the eyes of the opposing driver of a vehicle. (as traffi c laws stipulate - refer to p.6 for adjustment procedures) ● After installing the lamp, make sure the headlamps, wipers and horn are working normally. ● When the battery terminal is removed, memory related to the clock, radio, audio system etc, will be aff ected. After all work procedures are completed, reset to the original settings. (For adjustment procedures refer to your car's instruction manual) Caution Regarding Wiring / Please read thoroughly ● When installing the wiring harness, strictly follow the cautionary points mentioned below. Incorrect or faulty wiring may cause the lamp to operate incorrectly. In some cases, it may cause the vehicle to catch fi re. ● Before you begin always remove the (-) and (+) terminals. Always remove the (-) terminal fi rst and make sure a short does not occur.
-
Page 3: Product Details
PKI-0041-5-E ※ Verify all the parts are included. If a part is missing, please contact your local distributor. Product Details ※ Depending on mounting methods, some parts may not be used. Mounting method A Mounting method B ① Lamp main unit (1 unit) This product package contains one the following lamp unit types RF10 "RF6", "RF10" or "RF18" RF18 Parts to be used in Mounting method A. ② Installation ③ Hexagon head bolt ④ Hex nut（L ／ M10） ⑤ Rubber cushion bracket A (2pcs) (2pcs) (2pcs) (2pcs) ⑥ Hexagon socket head bolt ⑦ Slider (2pcs) ⑧ Hex nut（S ／ M10）... -
Page 4: Tools Required
PKI-0041-5-E ⑲ Connection bracket ⑳ Hexagon socket ㉑ Pre-assembled relay harness ㉒ Switch (1 pc) head bolt (M4) (2 pcs) with fuse【LR-39】 （1 set） (1 pc) ㉓ Double-stick tape ㉔ One-touch ㉕ Wire tie for switch (1 pc) connector (1 pc) (5 pcs) ㉖ Rubber cap ㉗ Dummy connector (2 pcs) (1 pc) ㉘ Hexagonal wrench ㉙ Hexagonal wrench ㉚ Hexagonal wrench ㉛ Hexagonal wrench (M10) (1 pc) (M8) (1 pc) (M6) (1 pc) ... - Page 5 PKI-0041-5-E Hexagon head bolt （2）Combine the Installation bracket (Item ② ) and the (Item ③ ) Hexagon head bolt (Item ③ ) as shown in the fi gure Installation bracket A below. (Item ② ) ● If installing the lamp main units RF10 and RF18 to the vehicles without combining them, make sure to install 2 Installation brackets on 2 positions on the lamp main unit. With unit RF6 , one Installation bracket can be used in the center but we recommend installing them on 2 positions. （3）Take 2 sets made up of the Hex nut and Slider assembly that was combined in (1) put them into the lamp main unit positions as indicated in the fi gure. Be careful not to drop the Hex bolt out of the Slider. Slider assembly （4）Take 2 sets made up of the Hex nut and bracket assembly that were combined in (2) and using the Hexagon socket head bolt (M10/Item ⑥ ), screw it fi rmly in place. Installation bracket A (Item ②...
-
Page 6: Lamp Installation
( Item ⑨ ) Side cap ( Item ⑨ ) Rubber cushion ( Item ⑤ ) Hex nut ( L/Item ④ ) Tightening torque：18ft・Ibs (24N・m) ● When using a commercially supplied lamp bracket, before removing the bolt that is already installed on the car body, make sure that it is safe to do so. ● The lamp should be mounted in an area suffi cient to support its size and weight. Failure to do so may result in excessive vibration leading to shorter bulb life and or physical damage to the lamp or your vehicle. ● Do not attempt to install the lamp directly to any plastic part of the car body. ● When installing, make sure the lamp body, lens and rim are not touching the bumper and other plastic parts. Such plastic parts might deform. ● The lamp installation surface should be fl at. ● The lamp should be tightened to the degree that the lamp body cannot be moved by hand. ● The lamps are designed to be mounted upright. It is very important that you make sure that the PIAA etched in the lens reads right side up. - Page 7 PKI-0041-5-E ※ The following work procedures shown below are for the 【3】Before starting the work procedures... "RF6" model but the same procedures can also be used for units "RF10" and "RF18". By using the Connection bracket (Item ⑲ ) 2 main lamp units (Item ① ) can be connected. When installing and using the main lamp unit, follow the ■ Lamp connection procedures indicated below. If not installing the main lamp unit using this procedure continue on to page 4, 【 1】 Installation preparations and follow the instructions indicated there. In addition, if not connecting the lamps, the connection brackets (Item ⑲ ) and the Hexagon socket head bolt (M4/Item ⑳ ) will not be used. Therefore, please store them properly for safekeeping. ■ Lamp connection procedures Install the Connection bracket (Item ⑲ ) to the nut on the lamp main unit as shown in the fi gure. Use the Hexagon socket head bolt (M4/Item ⑳ ) to secure it fi rmly in place. Lamp main unit (Item ①） Hexagon socket head bolt (M4) (Item ⑳）...
- Page 8 PKI-0041-5-E ● Use the recommended torque and apply equal force when tightening the Hexagon socket head bolt (M4/Item ⑳ ). ● If connecting 3 lamps in a row, make sure to install the right number of bracket(s) for each size f a lamp. ● When connecting lamp units RF6 and RF10 , we recommend that 2 Installation brackets A (Item ② ) be used on each lamp unit. If there is a problem with the installation position and only one Installation bracket A can be installed on each lamp, install it on the outer hole from center. Center Center Center Center Center Center Installation bracket A ● When installing and using RF18 unit, make sure to install 2 Installation brackets A (Item ② ) at 2 positions on each lamp. After installing the lamp, follow the P13 【7】Relay Harness Installation Sequence . ...
- Page 9 PKI-0041-5-E Mounting Method B 【4】Installation preparations Combine the lamp and install brackets B as shown in the fi gure below. Spring washer （S/M6）(Item ⑭ ) Hexagonal Washer (S/M6) wrench (M6) (Item ⑬ ) (Item ㉚ ) Installation bracket B (R) Hexagon socket (Item ⑪ ) head button bolt Installation bracket B (L) (S/M6) (Item ⑫ ) (Item ⑩ ) Tightening torque：6.6ft・Ibs (9N・m) Advice ● After the lamps are installed on the vehicle, the Hexagon socket head button bolts (S/M6） （Item ⑫ ) can be loosed and the angle of the lamp can be adjusted. Hexagon socket head button bolt Installation bracket B ...
- Page 10 (L/M8) (Item ⑮ ) Spring washer （L/M8）(Item ⑰ ) Washer (L/M8) (Item ⑯ ) Hex nut ( L/M8)(Item ⑱ ) ● When using a commercially supplied lamp bracket, before removing the bolt that is already installed on the car body, make sure that it is safe to do so. ● The lamp should be mounted in an area suffi cient to support its size and weight. Failure to do so may result in excess vibration leading to shorter life and or physical damage to the lamp or your vehicle. ● Do not attempt to install the lamp directly to any plastic part of the car body. If the lamp needs to be installed on the plastic reinforcement materials should be placed on both sides of the plastic part. ● When installing, make sure the lamp body, lens and rim are not touching the bumper and other plastic parts. Such plastic parts might deform. ● The lamp installation surface should be fl at. ● The lamp should be tightened to the degree that the lamp body cannot be moved by hand. ● The lamps are designed to be mounted upright. It is very important that you make sure that the PIAA etched in the lens reads right side up. -10-...
- Page 11 PKI-0041-5-E ※ The following work procedures shown below are for the 【6】Before starting the work procedures... "RF6" model but the same procedures can also be used for units "RF10" and "RF18". By using the Connection bracket (Item ⑲ ) 2 main lamp units (Item ① ) can be connected. When installing and using the main lamp unit, follow the ■ Lamp connection procedures indicated below. If not installing the main lamp unit using this procedure continue on to page 9, [4] Installation preparations and follow the instructions indicated there. In addition, if not connecting the lamps, the Connection brackets (Item ⑲ ) and the Hexagon socket head bolt (M4/Item ⑳ ) will not be used. Therefore, please store them properly for safekeeping. ■ Lamp connection procedures Install the Connection bracket (Item ⑲ ) to the nut on the lamp main unit as shown in the fi gure. Use the Hexagon socket head bolt (M4/Item ⑳ ) to secure it fi rmly in place. Lamp main unit (Item ①） Hexagon socket head bolt (M4) (Item ⑳） Nut sections Connection bracket Hexagonal wrench (M4) （Item ⑲） (Item ㉛ ) Tightening torque：2.2ft・Ibs (3N・m) -11-...
- Page 12 PKI-0041-5-E ● Use the recommended torque and apply equal force when tightening the Hexagon socket head bolt (M4/Item ⑳ ). ● Do not connect more than 2 lamp main units. ● Do not connect 2 units of "RF18" together using Mounting method B . -12-...
- Page 13 PKI-0041-5-E 【7】Relay Harness Installation Sequence The numbers shown in the fi gure below indicate the sequence the parts should be installed. Remove the (+) terminal from the Remove the (-) terminal from the Attach the (-) battery. battery. terminal to the battery. First ground the terminal Take the (+) terminal then take the (-) cord cord (white) and attach (black) and connect it to it to the (+) terminal and the (-) terminal. connect to the battery. Battery Make sure to properly Double-stick tape for switch. secure the relay unit Place in area that is easily using bolts or a harness. accessible from driver’s seat. The harness must also be facing downward. Switch Relay Facing down Bring the relay connector into the interior of the vehicle and connect Connect the lamp harness to the switch’s connector. to the connector. (+)cord (white) Take the (+) cord (white) and using the one-touch connector, tie it together to the vehicle’s (+) cord. Cord One-touch ...
- Page 14 PKI-0041-5-E DRIVING ／ Spot Light Aiming Typically, driving lights are mounted above the front bumper about 30 inches from the ground to provide extra high beam illumination. Driving lights can be mounted below the bumper, although they will not be as eff ective because the light will hit the ground sooner and reduce the range of the light. Visual aim is made with the center of the beam hot spot 1.5 inches below the lamp center at 25feet with the lamp facing straight forward. (see below.) ● Do not use driving lights into oncoming traffi c. Driving lights should never be the only forward light source. Driving lights should only be used with the headlamp high beams. 【8】Troubleshooting…… Verify each section according to the following. 1 After installation, if the lamp does not activate → Check the wiring and make sure there are no faulty or irregular connections . ● If the switch illumination does not light up. ...
-
Page 15: Repair And Replacement
EXCLUSIONS This Limited Warranty specifi cally excludes defects resulting from misuse, abuse, neglect, alteration, modifi cation, improper installation, unauthorized repairs, submersion, theft, vehicle crash, or by any other type of impact. Except for the Limited Warranty stated above, there are no warranties of PIAA products or any part thereof, whether express or implied. Any implied warranty of merchantability or any warranty of fi tness for a particular purpose is expressly disclaimed. Some states do not permit the disclaimer of implied warranties. LENS CRACKS Crash or impact damage is not covered. This can be determined by a chip or scrape on the lens or the housing. Stress cracks sometimes occur when the lens is subjected to sudden and extreme temperature changes. A stress crack has no chip or other sign of impact. Stress cracks are covered under warranty. EXCLUSION OF DAMAGES In no event shall PIAA be liable for any damages whatsoever (including, without limitation, consequential damages, incidental damages, or damages for loss of use, loss of business profi ts, business interruption, loss of business information, loss of time, inconvenience, or other losses) arising out of the use, misuse, or inability to use a PIAA product. PIAA reserves the right to change the design its products without any obligation to modify any previous product. This warranty gives you specifi c legal rights. You may also have other rights that vary from state to state. REPAIR AND REPLACEMENT If a PIAA product is suspected of being defective, it must be submitted freight prepaid, to either an authorized dealer or distributor for warranty inspection. The receipt or other proof of purchase and a description of the problem must be included. The returned product will be inspected. If the product is found to be defective and covered by this Limited Warranty, the sole remedy is repair or replacement, at PIAA's option. A repaired or replacement product will be shipped back at no charge, and will be warranted to be free from defects in workmanship and materials under normal use for as long as the original purchaser owns it. Removal, installation, or reinstallation costs are not covered by this Limited Warranty. PIAA CORPORATION www.piaa.co.jp www.piaa.com -15-...
