- Page 2 MCV1-FO-ETH User’s Manual The Exemys products are in permanent evolution to satisfy the needs of our clients. For this reason, the specifications and capabilities are subject to change without previous notice. Please find updated information at www.exemys.com Copyright © Exemys, 2009. All Rights Reserved.
- Page 3 MCV1-FO-ETH User’s Manual Contents Introduction Purpose of this manual General Description of the Product 2 Wiring General Wiring Configuration Technical Specifications Ordering codes www.exemys.com Rev. 2 – March 2015...
- Page 4 Its configuration and operation are described later in detail. 1.2 General Description of the Product The MCV1-FO-ETH are multi mode and single mode Ethernet to Optic Fiber Converter that allows the extension of communications up to 2 Km (10 Km in single mode) without electric noise interference.
- Page 5 MCV1-FO-ETH User’s Manual 2 Wiring 1.3 General Wiring MCV1 -FO-ETH wiring is very simple and intuitive. There are three different connectors. Ethernet port connector in RJ45 connector Optic fiber port connector in ST or SC connector according to device model.
- Page 6 MCV1-FO-ETH User’s Manual 3 Configuration The configuration of the converter is very simple and is made by means of jumper switches located in the top side of the device as shown in the following figure. There are two configuration jumper switches, both to configure the converter’s operation, from the optic fiber side: Flow Control: This can be activated or deactivated.
- Page 7 MCV1-FO-ETH User’s Manual 4 Technical Specifications 5 Ordering codes www.exemys.com Rev. 2 – March 2015...
