aguri SKYWAY User Manual

Hide thumbs Also See for SKYWAY:
Table of Contents

Advertisement

Quick Links

Download this manual
SKYWAY | Drive Assist
User Manual
www.aguriworld.co.uk
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKYWAY and is the answer not in the manual?

Questions and answers

Related Manuals for aguri SKYWAY

Summary of Contents for aguri SKYWAY

  • Page 1 SKYWAY | Drive Assist User Manual www.aguriworld.co.uk...

  • Page 2: Table Of Contents

    Choose between Radar + GPS GPS and Radar/Laser alerts, GPS alerts only or speed trap alert Radar alerts only screens explained Vehicle low battery warning How to update your Skyway GTX90 using a PC Factory reset Warranty Control Radar/laser alerts by speed...

  • Page 3: What's In The Box

    1 x User guide 1 x Sticky pad dash mount Please note that you must power your Skyway with the 12V cigarette lighter cable or the 12V hard-wire lead provided. Your Skyway will not work correctly if you attempt to power...

  • Page 4: Product Overview

    Please note that you must power your Skyway with the 12V cigarette lighter cable or the 12V hard-wire lead provided. Your Skyway will not work correctly if you attempt to power it via a 5V USB cable or the USB data socket on the side of the unit.

  • Page 5: Standby Screen Explained

    Attach the windscreen bracket by sliding it into the slot on the rear of the unit. (Attach the suction cups if they are not already attached) Using the suction cup bracket, mount your Skyway in a safe and convenient position in the front windscreen where it has an unobstructed view of the road ahead.

  • Page 6: Installing Your Skyway Using The Sticky Pad Dash Mount

    Once you have found a suitable location for the sticky pad and have checked that it will not move when driving, place the Skyway on to it. The unit should not move from the pad when driving but double check that it is secure before using.

  • Page 7: Installation Tips

    It is also possible to ‘hard-wire’ your Skyway and hide the power cables, providing a neater installation. Please contact an auto electrician or your local car dealer for further details.

  • Page 8: Menu Settings

    Speed trap alert settings It is possible to switch individual radar frequencies and speed traps on and off, to fine tune Skyway to the country you are driving in. Enter the settings menu by pressing and holding the ‘Menu’ button.
  • Page 9 Using Skyway in other countries outside of the UK. Below are the speed trap alert settings we would recommend for a selection of other countries if you want to use your Skyway outside of the UK. Germany/Austria Spain/Portugal Italy Radar/laser...

  • Page 10: Brightness Control

    • Dark – Stealth mode. Screen will remain black apart from one small white dot to indicate the unit is powered on and working. Your Skyway will continue to alert in this mode, but you will only receive audible alerts and no visual alerts.

  • Page 11: Choose Between Radar + Gps Alerts, Gps Alerts Only Or Radar Alerts Only

    City 2 Smart mode (recommended) If Smart mode is selected, your Skyway will start in City 2 up to 20mph, then switch to City 1 between 20mph and 30mph and will then automatically switch to Highway mode when you exceed 30mph.

  • Page 12: Vehicle Low Battery Warning

    ‘Menu’ button to confirm your selection and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically. Geo Radar alerts...

  • Page 13: Directional Alerts

    ‘Menu’ button to confirm your selection and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically. User POI. Add your own user point alerts Use this feature to add and create alerts for your own locations in your Skyways internal memory.

  • Page 14: How To Delete Your User Point Alerts

    POI you want to delete. The display will confirm that the user point has been deleted successfully. User note. It is also possible to manage your user points using the Skyway GTX90 updater. Please see instructions later on in this manual. Set audible alerts Use this setting to choose between the following audible alerts:- •...

  • Page 15: Automute Time

    ‘Menu’ button to confirm it and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically.

  • Page 16: City Smart Mute

    ‘Menu’ button to confirm your selection and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically.

  • Page 17: Select Preferred Speed Unit

    ‘Menu’ button to confirm your selection and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically.

  • Page 18: Gps Speed Calibration

    ‘Menu’ button to confirm your selection and return to the menu. Press and hold the menu button to return to the standby screen or wait a few seconds and your Skyway will return to the standby screen automatically.

  • Page 19: Gps And Radar/Laser Speed Trap Alert Screens Explained

    GPS and Radar/Laser speed trap alert screens explained Speed trap alert for fixed roadside speed traps such as HADECs 3 Smart Motorway cameras, Gatso cameras and Truvelo cameras. Speed limit (Background switches to white if you Driving mode are exceeding the limit) selected GPS - connected (Smart mode)
  • Page 20 SPECs average speed camera – alert start Speed limit (Background switches to white if you are Driving mode exceeding the limit) selected (City 1) GPS - connected Your speed SPECs Average speed Distance to 1st camera camera detected in the sequence SPECs average speed camera –...
  • Page 21 Mobile speed trap/police laser van location alert Speed limit (Background switches to white if you are Driving mode exceeding the limit) selected (City 2) GPS - connected Mobile speed trap/ police laser van Distance to speed trap Your current speed location detected Radar alert (Please note that you may also detect...

  • Page 22: How To Update Your Skyway Gtx90 Using A Pc

    Your current speed How to update your Skyway GTX90 using a PC Please note that your Skyway has been delivered with the latest software and speed trap database already pre-installed, so it will not be necessary to perform an update immediately.
  • Page 23 PC that you can easily find, and use it whenever you want to update your unit. Once you have opened the ‘Skyway GTX90 updater’ folder you should see the following information Double click on the GTX90_UserDownloader application to open it...
  • Page 24 ‘DB SW’ folder which contains the latest version of the Aguri Speedshield speed trap database. Next, connect your Skyway to your PC following the steps displayed on the Skyway GTX90 updater. 1. Connect you the USB cable to your computer.
  • Page 25 There are a total of five options that can be updated depending on what has been released for your unit. Each one correlates to one of the five folders that can be downloaded in the ‘Skyway GTX90 software and speed trap database’ folder.
  • Page 26 Managing your user points with the Skyway GTX90 updater You can also use the updater software to manage your user points. Click on the ‘POI’ tab to view any user locations you have added yourself. Select the user point you want to delete and press the ‘Delete’...

  • Page 27: Warranty

    Please note that to receive technical support or service under warranty, you must first register your unit at www.aguriworld.co.uk Having a problem with your Aguri Skyway GTX90 speed trap detector? Try visiting the FAQ section at www.aguriworld.co.uk. We find that most issues can be resolved there.
  • Page 28 www.aguriworld.co.uk...
