Seneca T201DCH600-MU Installation Manual

Ac/dc true rms or bipolar dc current transducer with modbus rtu protocol and analogue/digital output
Hide thumbs Also See for T201DCH600-MU:

Advertisement

Quick Links

INSTALLATION MANUAL
T201DCH600-MU
AC/DC true RMS or bipolar DC current transducer with
ModBus RTU protocol and analogue/digital output
EN
DOCUMENTATION
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
For manuals in other languages and the configuration software,
visit www.seneca.it/products/t201dch600-mu
MI00559-2-EN
1/4
