Summary of Contents for Zeta OPZ1ZT92
- Page 1 OPZ1ZT92 ZETA Light Sensor...
- Page 2 OPZ1ZT92 Copyright Statement ZiFiSense owns the copyright on this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of ZiFiSense. Disclaimer This specification is preliminary and is subject to change at any time without prior notice.
-
Page 3: Table Of Contents
OPZ1ZT92 Table of Contents 1. Product Description..........................4 2. Applications............................4 3. Features..............................4 4. Specifications............................ 5 5. Packing List............................5 6. Installation............................6 6.1. Screw............................6 6.2. Adhesive 3M.......................... 8 6.3. Cable Ties..........................9 . Use of Device........................... 12 8.1. Steps for usage........................12 8.2. -
Page 4: Product Description
OPZ1ZT92 1. Product Description ZETA Light Sensor is a low power illuminance detect sensor which is able to quantify the illuminance value and provide alarm signals if the threshold values are exceeded. 2. Applications Room lighting detection, lamp aging detection 3. -
Page 5: Specifications
OPZ1ZT92 4. Specifications Product No. OPZ1ZT92 Transmission protocol ZETA Sub-GHz, adjustable according to Frequency band Wireless Features local regulations 20dBm max, adjustable according Output power to local regulations Power supply Battery, 2*ER14505 Battery capacity 2*2700 mAh Electrical Features Stand-by current ≤... -
Page 6: Installation
OPZ1ZT92 6. Installation There are three installation methods: Screw, 3M Adhesive and cable ties. 6.1. Screw 6.1.1.Auxiliary material Materials Quantity self tapping screw (M3*20) 2/device #4 expanded plastic pipe Percussion drill，#4 drill bit，hammer slotted screwdriver, cross screwdriver Open the device case 6.1.2.Installation instructions... - Page 7 Use the self-tapping screws to secure the device in the mounting position. OPZ1ZT92 mounting hole mounting hole Power on Insert the power plug into the upper power socket, install two 14505 batteries (remove the insulation sheet for the existing battery), and close the upper cover.
-
Page 8: Adhesive 3M
OPZ1ZT92 6.2. Adhesive 3M 6.2.1.Auxiliary material Materials Quantity 3M seamless thickened double-sided adhesive Slotted screwdriver, utility knife Installation position 6.2.2.Installation instructions Select a flat mounting position, and clean it up. Open the device case Use a slotted screwdriver to open the top cover from the bottom edge. -
Page 9: Cable Ties
OPZ1ZT92 power socket Adhesive device Take the appropriate amount of 3M adhesive, attach it to the back of the sensor, remove the protective film of the 3M adhesive, and install the device to the specified position. 6.3. Cable Ties 6.3.1.Auxiliary material... - Page 10 OPZ1ZT92 opening Fixation Pass the 2 cable ties through the device and secure to the installation rod Installation position...
- Page 11 OPZ1ZT92 Power on Insert the power plug into the upper power socket, install two 14505 batteries (remove the insulation sheet for the existing battery), and close the upper cover. power socket...
-
Page 12: Use Of Device
OPZ1ZT92 7. Use of Device Place the device within the coverage of the ZETA network 7.1. Steps for usage Install the battery, and wait for the device to go online. After the device is online, the current device status is reported. -
Page 13: Common Faults And Handling
8. Common faults and handling Ensure ZETA signal coverage Ensure that the device is powered on, and the ZETA network device management platform can observe that the ZETA module is on line Check the battery usage of the device. When the battery is low, replace... - Page 14 FCC WARNING Any Changes expressly or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ...
- Page 15 OPZ1ZT92...
