ELITE KIT RACK ASSEMBLY INSTRUCTION
750ml 6 COLUMN 1/2 HEIGHT RACK
The following components are included in the 750ml 6 COLUMN 1/2 HEIGHT RACK.
COMPONENTS
(COMPONENTS WILL VARY IN QUANTITY AND SIZE, DEPENDING ON KIT.)
2 - Middle
1 - Left
Ladder 1034
Ladder 1034
(QTY: 1)
(QTY: 5)
Thank you for purchasing Elite Kit Rack by Genuwine Cellars. The following
instructions will help you assemble the 750ml 6 COLUMN 1/2 HEIGHT RACK.
The same procedure can be applied to the following kits shown.
Please study the instructions carefully prior to starting the assembly.
750ml 9 COLUMN 1/2 HEIGHT RACK
4a - Front Spacer Bars 689
(QTY: 3)
3 - Right
4b - Back Spacer Bars 689
Ladder 1034
(QTY: 3)
(QTY: 1)
750ml TASTING TABLE
6 - Base Mould 689
5a - Counter Top 689
(QTY: 1)
5b - Counter Nosing 689
(QTY: 1)
HARDWARE
The following hardware is included in all kits:
(QUANTITY WILL VARY, DEPENDING ON KIT.)
#8 Robertson Screws
Drywall Anchors
(Square Head)
(QTY: 4)
(QTY: 4)
#6 Robertson Screws
(Square Head)
Angled Brackets
(QTY: 4)
(QTY: 4)
TOOLS REQUIRED
The following tools are required (NOT INCLUDED):
IMPORTANT!
Always follow the manufacturer's
instructions on how to use the nail
gun, to prevent injury. Genuwine
Cellars is not liable for any injury
incurred while assembling the kit.
We Recommend A
21 Gauge Nail Gun
Robertson
(Use 21 gauge brand nails,
Screwdrivers #6 & #8
with appropiate air compressor
(Square Head)
or electric nailer set to 80psi,
to prevent spliting)
(QTY: 1)
