2. Install the side panels.
a. Align the four side panel holes with the corresponding mounting holes on the armrest, then push the side panel firmly
into place (Fig.A).
b. Using a flat-head screwdriver, pry the top of one of the fasteners up off of the fastener base and hold it in that position (Fig.B).
c. Using your other hand, locate one of the four side panel mounting holes on the inside of the armrest (Fig.C).
d. Push the base of the fastener firmly and completely into the hole, then push the top of the fastener firmly inward to lock it.
e. Repeat steps (b) and (c) to install the other three fasteners. NOTE: Access the upper rear mounting hole from the inside of
the arm, near the seat cushion. To install the upper front fastener, you may want to rotate the foot and calf massager for easier access.
f. Repeat steps (a) to (e) to install the other side panel.
Side panel
Fig. B
Fig. A
3. Install the power cord and power on the chair.
a. Plug the power cord into the power jack on the back of the chair.
b. Plug the other end of the power cord into a grounded 120V outlet.
c. Turn the power switch on the back of the unit to On (I).
4. Press the Power button on the remote control to power it on.
When you have ensured that the area around the chair is free from children and pets
(and will remain that way for the duration of the chair's use), select CONTINUE.
Fasterner
Mounting holes
Fig. C
Power cord
Power switch
HT -Navitas Sleep
DELIVERY AND ASSEMBLY GUIDE
Unpack the box
Armrests
Chair base
Power cord
Zip ties (4)
Fasteners (8)
Extra (in case needed)
Zip ties (2)
Fasteners (2)
5mm Allen screws (2)
Side panels
5mm Allen screws (8)
Flat washers (8)
5mm Allen wrench (1)
Flat washers (2)
1
Advertisement
Related Manuals for Human Touch HT-Navitas Sleep
Summary of Contents for Human Touch HT-Navitas Sleep
- Page 1 2. Install the side panels. a. Align the four side panel holes with the corresponding mounting holes on the armrest, then push the side panel firmly into place (Fig.A). b. Using a flat-head screwdriver, pry the top of one of the fasteners up off of the fastener base and hold it in that position (Fig.B). c.
- Page 2 CHOOSE A LOCATION ASSEMBLE THE CHAIR When deciding where to place your HT-Navitas, consider the following: 1. Install the armrests. • Place the unit on a flat surface, away from direct sunlight or any other direct heat source (to avoid fading). a. Align the four holes on the armrest mounting bracket with the corresponding holes on the chair frame. • If you wish to place the unit on a hard surface, it is recommended that you place a piece of carpet or a soft mat IMPORTANT: Orient the armrest with the open end facing backward, as shown.
