Summary of Contents for RBH Access Technologies Integra32

  • Page 1 Integra32 ™ Integrated Alarm Monitoring and Access Control HARDWARE MANUAL new generation building security...
  • Page 2 Neither RBH Access Technologies Inc. nor its dealers or distributors shall be liable to any person or entity with respect to any liability, loss, or damage, caused or alleged to have been caused directly or indirectly by this information.

  • Page 3: Table Of Contents

    Table of Contents T a b l e o f C o n t e n t s ™ CHAPTER 1 INTRODUCING INTEGRA32 ......................1 CHAPTER 2 INTELLIGENT FIELD PANEL ......................2 IRC2000 ..................................2 Connection Details ..............................2 Earth ..................................4 DIP Switch Settings ...............................
  • Page 4 ........................... 46 OSCH LARM ANEL NTERFACE ......................... 48 UMMIT LARM ANEL NTERFACE APPENDIX B: DIALUP MODEM CONFIGURATION ..................51 : ............................. 51 EMOTE ODEM : ..........................52 ERVER ODEM .............................. 60 ODEM ONNECTION ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 5: Chapter 1 Introducing Integra32

    RBH Access Technologies Inc. represents the latest in access technology specifically designed for smaller applications. Its intuitive graphical ™ interface allows users to take advantage of the power of the Integra32 with a minimal amount of training. The IRC-2000 Intelligent Field Panels utilize flash firmware for easy upgrades. The IRC-2000 panel uses fully distributed intelligence for off-line operations.

  • Page 6: Chapter 2 Intelligent Field Panel

    Readers are connected to non-programmable outputs BUZ, RED, & GRN, as well as data inputs D0 and D1. Both readers have their own connection terminals, reader A on the left side of the board and reader B on the right. ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 7 Chapter 1 Intelligent Field Panel ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 8: Earth

    For multiple panels always use only a single point ground reference for all panels. Bring the shields of all reader and communication cables back to one location. Do not connect them to the panel or the panel‟s housing. Grounding the Integra32 system IRC 2000 IRC 2000...

  • Page 9: Dip Switch Settings

    Use DIP switches 1, 2, 3, 4, and 5 to select the controller address. The address is binary coded and the switch settings for all sixteen possible addresses are given below. Controller Addressing Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Address ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 10 PC. The default PC baud rate is 38,400. Controller Baud Rate Selection DIP Switch 6 DIP Switch 7 Baud Rate 9,600 28,800 38,400 56,000 ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 11: Pc Connections

    The PC serial port used to connect to the IRC-2000 panels is assigned under the ™ Communication Port Setup screen of Network properties window in the Integra32 software. The baud rate is set by default to 9600 for direct connection to the PC using the standard RS232 interface.
  • Page 12 RS-485 connecter will be needed to connect the additional controllers to the modem controller. Cable Specification 4-conductor shielded, 18 to 22 AWG Maximum Cable Length 9600 baud 150 feet (45 meters) 56000 baud 50 feet (15 meters) ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 13 The RS485 interface allows the distance between the controller and the PC to be extended up to 4000 feet (1200 meters). RS485 requires one twisted pair shielded cable. Cable Specification Single twisted three-conductor, shielded, 18 to 22 AWG Maximum Cable Length 4000 feet (1200 meters) ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 14: Controller Networks

    RS485 terminals. Connect the TX/A terminal of one controller to the TX/A terminal next one, and connect the RX/B terminal to the RX/B terminal. All of the controllers on a network are connected in parallel. Controller Network Connection Diagram ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 15: Status Led's

    This LED (LED1) will be on if either (reader A or reader B) buzzer output is on. Fuses There are two 1-amp self-resetting Polyfuses on the IRC-2000 board. F1 is connected to Reader Power and F2 is connected to Main Power. Reader Power Fuse Main Power Fuse ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 16: Jumpers

    232 and all other JP1s to RS-485) Bias Low – RS485 tuning Leave jumpers JP2, JP3, and JP4 open. Do Termination – RS485 tuning not use these jumpers without consulting RBH. Bias High – RS485 tuning ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 17: Urc2000

    Readers are connected to non-programmable outputs BUZ, & LED, as well as data inputs D0 and D1. Both readers have their own connection terminals, reader A is designated as P4 and reader B is designated as P5. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 18 Chapter 2 Intelligent Field Panel ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 19: Earth

    Use DIP switches 1, 2, 3, 4, and 5 to select the controller address. The address is binary coded and the switch settings for all sixteen possible addresses are given below. Controller Addressing Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Address ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 20: Pc Connections

    The URC-2000 controller supports a two-wire RS485 interface. The RS485 interface allows the distance between the controller and the PC to be up to 4000 feet (1200 meters). RS485 requires one twisted pair shielded cable. ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 21: Status Led's

    Reader Power and F2 is connected to Main Power. Jumpers Bias Low – RS485 tuning Leave jumpers JP1, JP2, and JP3 open. Do not Termination – RS485 tuning use these jumpers without consulting RBH. Bias High – RS485 tuning ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 22: Elevator Control

    Chapter 2 Intelligent Field Panel Elevator Control Integra32™ Elevator Control uses a modified URC2000 board with ELC firmware. Up to four ELC-08 relays boards may be connect (strung) together for a maximum of thirty-two dry contact outputs per Elevator Control panel.

  • Page 23: Connection Details

    Chapter 2 Intelligent Field Panel Connection Details ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 24 Apply 12-24 volts DC to satisfy this input. When this voltage is removed all of the relays on the board will power down (turn ON), making all floors accessible. If the Fire Signal feature is not required install a jumper on the Fire Signal Bypass. ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 25: Pc100

    The PC-100 requires 9 to 14 volts DC and draws about 150ma. PC Interface The PC interface connects the PC-100 to a PC through an RS232 serial connection at 9600 baud only. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 26: Status Led's

    LAN interface module is attached to the PC100. This will connect the PC Interface port to the LAN interface module for the purpose of programming it. ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 27: Chapter 3 Input & Output Connections

    General Purpose Inputs are inputs that are not tied directly to an access point. The user defines what happens when they change state. They can trigger links, cause alarms, and/or report their change of state. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 28: Input Circuit Types

    Normally Closed, No Resistor Loop Resistance State Short Restore Open Circuit Alarm Normally Open, No Resistor Loop Resistance State Short Alarm Open Circuit Restore ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 29 State Short Trouble Restore Alarm Open Circuit Trouble This circuit provides a high degree of supervision and detects both short and open circuit fault conditions. Use this circuit in high security applications. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 30 Chapter 3 Input & Output Connections Normally Open, One Resistor Loop Resistance State Short Alarm Restore Open Circuit Trouble Normally Open, Two Resistor Loop Resistance State Short Trouble Alarm Restore Open Circuit Trouble ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 31 Normally Open And Normally Closed, One Resistor Loop Resistance State Short Alarm Restore Open Circuit Alarm This circuit type is used where normally open and normally closed contacts are used in the same loop. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 32: Outputs

    General Purpose Output General Purpose Outputs are outputs that are user controlled. They are activated and de- activated by user defined links and schedules. ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 33: Switching Inductive Devices (Locks, Bells)

    Connect the diode cathode (end with band) to the positive terminal and the other end to the negative terminal. The diode must be placed at the device being switched and not at the controller ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 34: Relay Output Operation

    For magnetic locks, the relay should be configured from the PC as „On State‟ de- energized for fail-safe operation. If power fails (AC and battery), the power to the magnetic lock is removed and the door is opened. ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 35 Door Strike Connection Diagram Handicap Output Connection Diagram If this output is used with an inductive load, use a back EMF diode (as described on page 29) to prevent damage to other equipment. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 36: Access Point Operating Modes

    The Buzzer emits one long beep and the green LED turns on for the duration of the unlock time. Access Denied The Buzzer emits two short beeps and the red led flashes twice. ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 37: Exit Reader Interface Connection Diagrams

    IRC2000 connect the SIG terminal of the interface to the TAM terminal on the reader port. If you are connecting to a URC2000 connect the SIG terminal to appropriate A or B terminal as indicated by the diagram below. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 38: Urc-2000 Connection

    Chapter 3 Input & Output Connections URC-2000 Connection For more information on the Exit Reader Interface check „TB51 Exit Reader Interface.pdf‟. ™ Integra32 Hardware Guide RBH Access Technologies Inc.
  • Page 39 Specifications S p e c i f i c a t i o n s ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 40: Irc-2000 Specification

    H 12in. x W 14in. x D 3½in. Operating temperature: 0 to 70C (35 - 150F) Operating Humidity: 20 to 80% RH (non-condensing) PC Connection: Can be connected via RS232, RS485, or by Modem ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 41: Urc-2000 Specification

    Dallas DS1994 with battery back up Board dimensions: H 3in. x W 6½in. Operating temperature: 0 to 70C (35 - 150F) Operating Humidity: 20 to 80% RH (non-condensing) PC Connection: Can be connected via RS485. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 42: Pc-100 Specification

    Board dimensions: H 4¼in. x W 4¾in. Operating temperature: 0 to 70C (35 - 150F) Operating Humidity: 20 to 80% RH (non-condensing) PC Connection: Can be connected via RS232, RS485, or by Modem ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 43: Elc-08 Specification

    Maximum of 4 Network Connection: Type RS-485 Relay Outputs: 1A @ 30vdc Board dimensions: H 3in. x W 6½in. Operating temperature: 0 to 70C (35 - 150F) Operating Humidity: 20 to 80% RH (non-condensing) ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 44: Cable Specification

    Single twisted pair, shielded 18 to 22 AWG Maximum Cable Length 4000 feet (1200 meters) Input / Output Port Circuit Loop: 2-conductor, 20 to 22 AWG Maximum Cable Length 1000 feet (300 meters) ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 45: Index

    Controller Network ..........10 Inputs ............... 23 Door Strike ............31 Intelligent Field Panel ..........2 Electronic Output ..........29 Introducing Integra32 ..........1 Handicap Output ..........31 IRC2000 IRC-2000 ............. 33 Baud Rate Selection ..........6 Magnetic Lock ............. 30 Connection Details ..........
  • Page 46 RS485 Connection Run LED .............. 17 IRC-2000 ............... 9 Specification ............37 URC-2000 ............16 Status LED's............17 RTE ..........See Request to Exit Wiring Diagram ........... 14 Run LED ..............11 ™ Integra32 Hardware Guide RBH Access Technologies Inc.

  • Page 47: License & Warranty

    Notice 1.02 RBH Access Technologies Inc. makes no claim or warranty with respect to the fitness of any product or software for a specific application and assumes no responsibility for installation. This warranty is in lieu of all other warranties expressed or implied.

  • Page 48: Appendix A: Pc-100 Interface Applications

    Communication Channel LEDs – Each communication channel has a green transmit LED and a red receive LED. Normally flashing at a rate of once a second, DIAG2 will flash twice as fast if the unit is offline with the Integra network. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 49: Dsc Alarm Panel Interface

    DSC alarm panel interface. When an input changes state on the alarm panel the PC100 will report the change of state as if it happened on its own panel. Status Display ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 50: Bosch Alarm Panel Interface

    “DIAG2” LED will turn on. The green “DIAG2” LED will turn off when the alarm panel finishes its poll to the keypad. Do not overload the power supply by connecting the IRC2000‟s along with their weigand readers to the Bosch +12v supply. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 51 Appendix 1 Specification Sheets ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 52: Summit Alarm Panel Interface

    2) (RS485) Panel – for connection to the LSCP bus on the Summit alarm panel. 3) (RS485) IRC – for connection to the Access control system. All channels are programmed for a baud rate of 9600 8-bits no parity and all Integra32™ panels need to be programmed for 9600 baud.
  • Page 53 For multiple combinations of inputs/outputs and events a spare output on an IRC panel can be assigned this functionality, through the use of links. The output can be assigned to a Summit input and instructed to follow. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 54 Appendix 1 Specification Sheets ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 55: Appendix B: Dialup Modem Configuration

    Set DIP Switches 1 through 5 to define the IRC2000‟s address. ® RBH recommends a U.S.Robotics external Sportster modems and a baud rate of 9600. Make any DIPswitch settings on your modem as per your modem manual and the Integra32™ hardware manual. Parameter Setting Auto Answer (AA)

  • Page 56: Server (Host) Site Modem

    Once the modem has been installed, you may edit the settings to correspond with the remote site(s) settings. In Figure 2, right click on modem and select properties to open modem properties window. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 57 Appendix 1 Specification Sheets Figure 2: Opening modem properties from device Manager. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 58 6. Use the Properties button to set the desired modem parameters e.g. Max. Speed of 9600 for a 56.6k modem. Use parameters appropriate for the remote site that you are connecting to. Figure 3: Modem properties ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 59 Appendix 1 Specification Sheets Set Advanced Connection Settings as follows. Include „Extra Initialization Commands‟ of &N6 to further force a baud rate of 9600. Figure 4: Modem Properties ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 60 Appendix 1 Specification Sheets Click on Query Modem button (Figure 5), and you will see „success‟ message (Figure 6). Otherwise, you will see „communication fails‟ message (Figure 7). Figure 5: Modem Diagnostics properties ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 61 Appendix 1 Specification Sheets Figure 6: modem Query results Figure 7: Modem Query error message. ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
  • Page 62 Configure Modem COM Port on the Integra32 Server ™ Open the Network Properties window in the Integra32 Database Manager. Click on Port Type and select Modem Network. Use the Modem combo box down arrow and select the modem from those already setup under Windows.
  • Page 63 Appendix 1 Specification Sheets  Note: Panel modem side 25 pin DB connector wiring diagram is incorrect. Please refer to diagram below ™ RBH Access Technologies Inc. Integra32 Hardware Guide...

  • Page 64: Modem Connection

    RS-485 connecter will be needed to connect the additional controllers to the modem controller. Cable Specification 4-conductor shielded, 18 to 22 AWG Maximum Cable Length 9600 baud 150 feet (45 meters) 56000 baud 50 feet (15 meters) ™ RBH Access Technologies Inc. Integra32 Hardware Guide...
