Joy MagConnect VESA Quick Start Manual

Hd forklift mount

MagConnect

HD Forklift Mount

Compatible with

VESA 75x75mm

100x50mm and

100x100mm

conﬁgurations

(hardware is not

included)

38mm or 26mm

VESA Ball Joint

or VESA

™

Always release the

bracket to adjust parts

Up to 3" height

(Up to 3" wide)

38mm or 26mm

MagConnect Ball Joint

Up to 3" wide

MagConnect Cases &

Module Compatible

(Not Included)

Table of Contents

Need help?

Do you have a question about the MagConnect VESA and is the answer not in the manual?

Page 1 MagConnect or VESA ™ HD Forklift Mount (Up to 3" wide) Compatible with VESA 75x75mm 100x50mm and 100x100mm conﬁgurations MagConnect Cases & (hardware is not Module Compatible included) (Not Included) 38mm or 26mm 38mm or 26mm VESA Ball Joint MagConnect Ball Joint Always release the bracket to adjust parts Up to 3"...
Page 2 Content List MagConnect SKU#: VESA SKU#: MagConnect or VESA MMU330 (38mm) MVU330 (38mm) MMU230 (26mm) MVU230 (26mm) Ball Joint VESA 50/75/100 Compatible Magnet Precision Compatible with VESA dial rotate 75x75mm, 100x50mm to secure and 100x100mm conﬁgurations MagConnect Cases & Module Compatible (hardware is not included) (Not Included)
Page 3 Arm Installation Assemble spring and lever Thread on cap clockwise, do not fully insert Insert base ball joint into arm Insert the MagConnect / VESA ball joint Turn lever clockwise until hand-tight Push lever down Always release the lever to adjust parts Insert screw into the end cap and fully tighten down...
Page 4 The Joy Factory will replace your Tablet mount if it has any manufacturing defects, free of charge, for one year from the date of purchase. If you believe the mount has a manufacturing defect, cease use immediately and contact The Joy Factory by email at support@thejoyfactory.com or by telephone at (949) 216-8888,...
