- Page 1 Elevate II Tilting & Rotating Module Assembly Instructions 90˚ 75˚ Contents A x1 C x1 B x1 D x1...
- Page 2 Installation / User manual Loosen Using the included wrench(S6), loosen nut (A1) and remove all pieces (A1-A6). Metal opening facing forward Place hinge (A) on top of plastic washer (B) & Kiosk pole. Install the 4 screws (S1) into the pole neck to 2 o'clock secure the hinge down.
- Page 3 (outter circle) hinge and second circle of the 4 holes (inner circle) to install the enclosure with the corresponding screws. for Metal Enclosure Washer(S4) needed © The Joy Factory, Inc. Email us at support@thejoyfactory.com or call us at +1(949) 216-8888...
