INSTALLATION GUIDE MagConnect HD Seat Bolt | Bolt Mount
Choose a location
Flat Horizontal Surface: Follow
Mounting Option 1 on page 2.
™
Seat Bolt | Bolt Mount
There are four different mounting options that can be
utilized for securing the mount to a vehicle bolt. There
are a few things to consider when choosing the best
location for the bolt mount. When possible the arm at the
base of the mount should run perpendicular to the
vehicle floor. This provides ultimate support of the
mount. Included are three bolt brackets along with a
base that should be utilized to accomplish this.
Choose the best option based on the hardware in the
vehicle while ensuring configuration provides optimal
mount stability.
Support
For questions or concerns please contact us at:
Customer Service Support
Toll Free: +1.877.JOY.FACT (877.569.3228)
support@thejoyfactory.com
Flat Horizontal Surface Obstructed
Bolt: Follow Mounting Option 2 on
page 2.
Flat Vertical Surface: Follow Mount-
ing Option 3 on page 3.
1
Package Contents:
(a) 90º raiser bracket x1 (g) screw nuts x2
(b) 90º bracket x1 (h) support foot x1
(c) 180º bracket x1 (i) support foot cap x1
(d) support bracket x1 (j) base x1
(e) washer x1
(f) screw x1
(b)
(a)
(d)
(e)
(g) (h)
(i)
Angeled Surface: Follow Mounting
Option 4 on page 3.
(c)
(f)
(j)
