EdgeStar SW5L 30D Owner's Manual page 17

19/01/2006
Code Esp. N.Ref.
CFF050 D441018400 FILTER RING
CFF060 D350003500 FILTER CAP
CFF070 D402038600 DRAIN OUTLET BEND
CFF080 D398013000 FILTER-PUMP CONNECTION
CFF090 D414004300 DRAIN PIPE
CFF100 D440000500 HOSE CLAMP CONNECTION FOR FILTER-PUMP
CFF110 D440001700 HOSE CLAMP FOR DRAIN OUTLET BEND
CFF120 D432008700 FILTER BODY SCREW
CFF130 D432009800 ELECTROPUMP SCREW
CFF140 D398019400 U BOLT FOR DRAIN PIPE BEND
CFF150 D440000400 DRAIN PIPE HOSE CLAMP
CFF190 D414013900 PRESSURE SWITCH PIPE
CFF190 D720334800 PRESSURE SWITCH PIPE
CFG001 D441028500 MOTOR FIXING SPLIT PIN
CFG002 D443013200 MOTOR FIXING PIN
CFG005 D526011900 THERMO-RESISTANCE
CFG005 D526011900 THERMO-RESISTANCE
CFG005 D526011900 THERMO-RESISTANCE
CFG010 D258002100 SPRING HOOK CROSSPIECE
CFG020 D490000700 UPPER COUNTERWEIGHT
CFG020 D490011600 UPPER COUNTERWEIGHT
CFG030 D726011400 TUB
CFG037 D432016700 MOTOR PIN FIXING SCREW
CFG039 D398101400 DRUM PADDLE
CFG060 D402004300 TUB GASKET
CFG070 D441016900 LOCKING-RING FOR TUB
CFG080 D490005600 BOTTON COUNTERWEIGHT
CFG090 D236012300 DRUM FLANGE
CFG100 D499004900 FRICTION PADS
CFG110 D444000600 DAMPER SPRING
CFG120 D441009700 DAMPER BUSH
CFG130 D512019100 MOTOR
CFG140 D524018600 HEATING ELEMENT
CFG160 D268006700 PULLEY PIPING
CFG170 D416002300 BELT
CFG200 D444017600 SUSPENSION SPRING FOR TUB
CFG200 D444018700 SUSPENSION SPRING FOR TUB
CFG210 D434000300 PULLEY NUT
CFG220 D446000200 BEARING
CFG230 D446000300 BEARING
CFG240 D441017500 SEALING RING
CFG290 D434002100 NUT COUNTERWEIGHT
CFG300 D436008500 COUNTERWEIGHT WASHER
CFG300 D436013600 COUNTERWEIGHT WASHER
CFG310 D398105200 BOSS COUNTERWEIGHT
CFG320 D430007100 SCREW FOR UPPER COUNTERWEIGHT
CFG320 D430007600 SCREW FOR UPPER COUNTERWEIGHT
CFG340 D434002100 TUB RING NUT
CFG350 D436000500 TUB RING WASHER
CFG360 D430025600 TUB LOCKING-RING SCREW
CFG380 D430014000 MOTOR SCREW
CFG400 D441022600 MOTOR BUSH
CFG400 D441031400 MOTOR BUSH
CFG410 D434002100 MOTOR NUT
CFG430 D499003600 SPRING FIXING RING
CFG440 D432004600 SPRING CROSS PIECE SCREW
CFG450 D430018800 LOWER COUNTERWEIGHT SCREW
CFG460 D268003500 DAMPER CONNECTING PLATE
CFG480 D716008900 TUB COVER
CFG530 D720386700 FLANGE + BASKET UNIT
CFG540 D428012500 MOTOR FIXING SPACER
SPARE PARTS PRICE LIST
Item Description
SW5L30D
Pag 3
Quantity Expiry Unit
Of Pieces Date Price
1
1
1 10
1
1 12
2
1
2
2
1
1
1
1
1
1
1 28.04.2005 10
1 10
1 01.01.2005 10
1
1 09.01.2006
1
1 63
1
4
1 10
1 12
1 12
1 50
4
2
2
1 58
1 10
1 13
1 20
1
1
1
1 10
1 12
1
5
5
5 10.05.2005
3
1
1
1
1
1
1
3 01.04.2005
3
1
2
4
3
2
1 53
1 90
1
2
3
4
2
2
1
1
5
2
2
2
2
4
7
7
7
1
7
4
7
2
3
3
1
5
1
1
1
1
1
1
1
1
1
1
2
2
1
3
1
1
3
1
