Kvill RE
Installation manual
Ø 430 mm
1
Turn bracket for semi
3
recessed mode (x3).
Aura Light AB, Sweden
Phone customer service +46 (0)20 32 30 30
info@auralight.com, www.auralight.com
2 a
2 b
Recessed mode.
2
Tighten the lock bracket
towards the ceiling (x3).
Thickness ceiling:
min. 1 mm
max. 115 mm
x3
Note: Make sure the lock
bracket is perpendicular
against the ceiling.
Semi recessed mode.
2021-11-30
x3
I-177
Advertisement
Table of Contents
Related Manuals for Aura Light Kvill RE
Summary of Contents for Aura Light Kvill RE
- Page 1 115 mm Turn bracket for semi recessed mode (x3). Note: Make sure the lock bracket is perpendicular against the ceiling. Recessed mode. Semi recessed mode. Aura Light AB, Sweden Phone customer service +46 (0)20 32 30 30 2021-11-30 I-177 info@auralight.com, www.auralight.com...
- Page 2 Level bracket. Dimensions semi recessed Dimensions recessed Non-replaceable light source. Replaceable control gear by a professional. Aura Light AB, Sweden Phone customer service +46 (0)20 32 30 30 2021-11-30 I-177 info@auralight.com, www.auralight.com...
