Ribes
Installation manual
Installation Steps
1: Install the track to the ceiling as shown in picture 1.
2: Turn the power supply to position 1 and then rotate
the shift as shown in picture 2.
3: Assembly the track head into track as shown in picture 3.
4: Rotate the shift to 90° as picture 4, rotate 1/2/3 as your
requirement, switch can rotate 3550 in clockwise and
anticlockwise as shown in picture 4.
5: Installation is complete as shown in picture 5.
2a
2b
2
4b
4a
4
Aura Light AB, Sweden
Phone customer service +46 (0)20 32 30 30
info@auralight.com, www.auralight.com
3
5
1
1a
1b
1c
3a
2021-02-09
I-162
