- Page 1 TD Series Thermal Imaging Cameras Quickstart Guide V1.0 202109 Thank you for purchasing this product. Please read this Guide first and keep it properly for future reference. The picture is for reference only, the product shall prevail in kind.
-
Page 2: Table Of Contents
- CONTENTS - IMPORTANT .................1 FCC WARNING..............1 NOTES ................2 LIST OF PARTS ..............5 PRODUCT COMPONENTS ............ 6 QUICKSTART INSTRUCTIONS ..........8 TROUBLESHOOTING ............13 STORAGE AND TRANSPORT ..........14... -
Page 3: Important
This Guide is prepared to introduce our products to the users. We will try our best to ensure the accuracy of the Guide, but the completeness of the Guide still cannot be guaranteed, because our products have been continuously upgraded. We reserve the right to modify at any time without prior notice. -
Page 4: Notes
- NOTES - DANGER 1) Please follow the method described in this Guide for charging the cell, and follow the charging procedures and precautions. Improper charging may cause overheating, damage and even personal injury; Do not attempt to open or disassemble the cell at any time. - Page 5 accessories to avoid damage. 6) Do not disassemble the unit by yourself, which may cause damage to the device and loss of warranty rights. 7) Do not use soluble or similar liquid on the device and cables, which may cause damage to the device.
- Page 6 environment or near high-temperature objects. 11) Do not short-circuit the positive and negative terminals of the cell. 12) Do not place the cell in a humid environment or the water. NOTES 1) Do not expose the device to dust or moisture. When used in an environment with water, avoid splashing water on the device.
-
Page 7: List Of Parts
- LIST OF PARTS - Number Items 18650 CELL MICRO USB CABLE VIDEO CABLE WRIST STRAP 18650 CHARGER 18650 CELL MICRO USB CABLE VIDEO CABLE WRIST STRAP 18650 CHARGER... -
Page 8: Product Components
- PRODUCT COMPONENTS - This Guide is applicable to several models of this series, and the illustration is only for one of them. CELL COVER BUTTON COLOR PALETTES BUTTON ZOOM-IN KNOB BRIGHTNESS KEY POWER BUTTON FOCUS RING DIOPTER REGULATION VIDEO... - Page 9 1. FOCUS RING After the thermal imaging camera is turned on, it shall be aimed at the target. When the distance between the observation target changes, the image may be blurred. Therefore, it is necessary to turn the lens focus ring to refocus until the target image is clear.
-
Page 10: Quickstart Instructions
- QUICKSTART INSTRUCTIONS - CURRENT BUTTON SHORT PRESS LONG PRESS DEVICE STATUS Power on (menu bar not Compensation Display off/off shown) POWER BUTTON Power on Power on Display on upon Display off Display on key release Focus far (some models) Menu bar not Switch display shown... - Page 11 【BUTTON DESCRIPTION】 1. POWER BUTTON · Power on Long press and hold the power button until the startup picture appears in the eyepiece, then the device can be switched on successfully. · Power off Manual power-off: long press and hold the power button, the power-off progress bar will be displayed, and the power-off succeeds after the progress bar is finished.
- Page 12 short-press the power on/off button to complete the corresponding compensation action. 2. BRIGHTNESS KEY · Adjust screen brightness Short press the brightness key to switch to the screen brightness. · Focus far (some models) Long press and hold it to focus far. ·...
- Page 13 not called up, short press the knob to switch to magnification and PIP. · Focus near (some models) Long press and hold it to focus near · Hot track (some models) Long press and hold it to adjust the hot track. 【FUNCTION DESCRIPTION】...
- Page 14 NOTE: The adjusted brightness value will be saved in the current scene mode. 6. Hot track A white cross cursor is displayed when it is turned on to trace the highest temperature point in the full image. 7. Scene mode Three scene modes, natural/enhanced/highlight, can be set.
-
Page 15: Troubleshooting
- TROUBLESHOOTING - 1. The device fails to start Solution: Replace the cell or connect the adapter for charging. 2. The screen goes out during use Solution: Short press any key to wake up sleep and light up the screen. 3. -
Page 16: Storage And Transport
- STORAGE AND TRANSPORT - The following is the correct storage and transportation of the product. To prevent danger, property loss, etc., please read the manual carefully before using the device Strictly observe it, and keep the instruction properly after reading it. - Page 17 Special statement: the version of the Guide will be updated after the technical improvement of the product. Guide Sensmart http://www.guideir.cn Adress: No.6 Huanglongshan South Rd, Wuhan, 430205, P.R.China...
