Arcteq AQ-110x Instruction Manual

Arc sensor unit with overcurrent
Table of Contents

Advertisement

Quick Links

AQ-110x
Arc sensor unit with overcurrent
Instruction manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQ-110x and is the answer not in the manual?

Questions and answers

Summary of Contents for Arcteq AQ-110x

  • Page 1 AQ-110x Arc sensor unit with overcurrent Instruction manual...
  • Page 3: Table Of Contents

    .......................... 45 11.1 Mounting and installation ....................45 11.2 Operating times ......................... 46 11.3 Auxiliary voltage......................... 46 11.4 Current measuring circuits....................46 11.5 Binary inputs........................46 11.6 Trip relays .......................... 47 11.7 High-speed output(s) ......................47 © Arcteq Relays Ltd IM00009...
  • Page 4 11.15 Casing..........................50 12 Or 12 Ordering inf dering informa ormation tion ..............................................51 13 Contact and r 13 Contact and re e f f er erence inf ence informa ormation tion......................................53 © Arcteq Relays Ltd IM00009...
  • Page 5 Nothing contained in this document shall increase the liability or extend the warranty obligations of the manufacturer Arcteq Relays Ltd. The manufacturer expressly disclaims any and all liability for any damages and/or losses caused due to a failure to comply with the instructions contained herein or caused by persons who do not fulfil the aforementioned requirements.
  • Page 6 A A Q Q -110x -110x Instruction manual Version: 2.01 Copyright Copyright © Arcteq Relays Ltd. 2021. All rights reserved. © Arcteq Relays Ltd IM00009...
  • Page 7: Document Inf

    A summary of connecting fiber sensors also added to the chapter. - All technical data checked and updated where necessary. - Ordering information updated. - Images updated where necessary. © Arcteq Relays Ltd IM00009...
  • Page 8 - The IP classification of point sensors updated. - The AWG value updated. - "Disturbance tests" table reformatted. - Order code images updated (separated the codes for AQ-110P and AQ-110F). - The number for Arcteq's technical support added to the reference information. © Arcteq Relays Ltd IM00009...
  • Page 9: Abbr Bbre E Via Viations Tions

    NO – normally open PCB – printed circuit board QD – quenching device RF – radio frequency Rx – receiver SAS – standard arc scheme SF – system failure Tx – transceiver μP - microprocessor © Arcteq Relays Ltd IM00009...
  • Page 10: General

    3.1 Unit features AQ-110x is a multipurpose arc flash protection unit and can be applied to a variety of applications. It can be used on its own as a stand-alone unit, or it can be a part of a more complex arc protection system through the binary bus.
  • Page 11 A A Q Q -110x -110x Instruction manual Version: 2.01 • nineteen (19) indication LEDs • one (1) push button. Figure. 3.1 - 1. Arc protection unit AQ-110P. Figure. 3.1 - 2. Arc protection unit AQ-110F. © Arcteq Relays Ltd IM00009...
  • Page 12: Dimensions And Installation

    Instruction manual Version: 2.01 3.2 Dimensions and installation AQ-110x can be either door-mounted or panel-mounted in a standard 19 inch rack. The unit's dimensions (without cards) are as follows: • Height: 157 mm (6.18 in) • Width: 102 mm (4.02 in) •...
  • Page 13: Simplified Block Diagram

    The following figure presents how to install an AQ-110x unit into a cut-out. Figure. 3.2 - 4. Installing a unit into a cut-out. 3.3 Simplified block diagram The figures below presents the main components that can be found in the AQ-110x units (AQ-110P and AQ-110F). © Arcteq Relays Ltd...
  • Page 14 A A Q Q -110x -110x Instruction manual Version: 2.01 Figure. 3.3 - 5. Simplified block diagram of AQ-110P. © Arcteq Relays Ltd IM00009...
  • Page 15 A A Q Q -110x -110x Instruction manual Version: 2.01 Figure. 3.3 - 6. Simplified block diagram of AQ-110F. © Arcteq Relays Ltd IM00009...
  • Page 16: Wiring

    L> / L> + I> S1: P> / L> S5: Fiber loop / AQD a / b FAST / CBFP Scheme 100 ms / 150 ms selection I>: 1A / 5A I0>: 1A / 5A © Arcteq Relays Ltd IM00009...
  • Page 17 S2: L> / L> + I> HSO latch: on / off S3: L> / L> + I> (N/A) a / b (N/A) FAST / CBFP Scheme 100 ms / 150 ms selection I>: 1A / 5A I0>: 1A / 5A © Arcteq Relays Ltd IM00009...
  • Page 18: Operation And Config Tion And Configura Uration Tion

    Verify the system A configuration mismatch condition (see the ERROR A system failure has has been detected. The system is healthy. "System self-supervision" (red) occured. Protection is partially and "Troubleshooting" operational. chapters). © Arcteq Relays Ltd IM00009...
  • Page 19: Push Button (Set)

    SET, and it can be used for all operational functions. The push button is used for setting up the system (also known as auto-configuration), for resetting the indicator LEDs and the latched output relays, as well as for checking the input connection. © Arcteq Relays Ltd IM00009...
  • Page 20: System Setup (Auto-Configuration)

    Unless the button is pressed, the latched trip relays remain active until the auxiliary power is disconnected. All LED indications also remain active even when the auxiliary power supply is disconnected unless the button is pressed. Please refer to the "Non-volatile memory" chapter for more information. © Arcteq Relays Ltd IM00009...
  • Page 21: Input Connection Check

    4.4 Current threshold settings The AQ-110x units have four (4) current measurement inputs: three (3) measure phase currents and one (1) measures the residual current. Both the phase and residual current measurements are used as secondary trip criteria in an arc protection system to avoid trips caused by natural light sources.
  • Page 22: Dip Switch Settings

    Tripping on light and overcurrent The tripping criterion for the S2 (L> + I>), both of which are (S2: L> or or L> + Tripping on light only (L>). sensor channel. required to occur simultaneously I>) to trigger tripping. © Arcteq Relays Ltd IM00009...
  • Page 23 (100 ms or or 150 ms) The nominal current selection for the phase currents IL1, IL2 and The nominal current is 1 A. The nominal current is 5 A. (I>: 1 A or or 5 A) IL3. © Arcteq Relays Ltd IM00009...
  • Page 24: Scheme Selection

    AQ-SAS™ booklet (can be found at arcteq.fi/downloads/). Please note that there are four booklets: two are for schemes based on IEC standards (MV and LV versions) and the other two for schemes based on ANSI standards (MV and LV versions).
  • Page 25 (MT) signal is sent to all outgoing feeder AQ-101 units (if these are used). You can find a more detailed description of this scheme in the AQ-SAS booklet. © Arcteq Relays Ltd IM00009...
  • Page 26 A A Q Q -110x -110x Instruction manual Version: 2.01 Figure. 4.5.2 - 16. The logic diagram of SS:1a. Figure. 4.5.2 - 17. The DIP switch settings for SS:1a. Figure. 4.5.2 - 18. The trip logic matrix of SS:1a. © Arcteq Relays Ltd IM00009...
  • Page 27 (MT) signal to trip all outgoing feeder circuit breakers. You can find a more detailed description of this scheme in the AQ-SAS booklet. Figure. 4.5.2 - 19. The logic diagram of SS:1b. Figure. 4.5.2 - 20. The DIP switch settings for SS:1b. © Arcteq Relays Ltd IM00009...
  • Page 28 (MT) signal is sent to all outgoing feeder AQ-101 units (if these are used). You can find a more detailed description of this scheme in the AQ-SAS booklet. Figure. 4.5.2 - 22. The logic diagram of SS:2a. © Arcteq Relays Ltd IM00009...
  • Page 29 (MT) signal to trip all outgoing feeder circuit breakers. The binary output BO1 is responsible for sending overcurrent information to a AQ-110P unit at another incoming feeder. You can find a more detailed description of this scheme in the AQ-SAS booklet. © Arcteq Relays Ltd IM00009...
  • Page 30: Non-Volatile Memory

    All critical system data (such as DIP switch settings and the system setup file) are stored in the non- volatile memory (EPROM) to ensure accurate operation and full self-supervision even if auxiliary power is lost temporarily. © Arcteq Relays Ltd IM00009...
  • Page 31 This feature is especially important if tripping causes the unit to lose its auxiliary power. The non-volatile memory does not require a power supply to maintain the information and it retains the settings and the indications permanently without power. © Arcteq Relays Ltd IM00009...
  • Page 32: Arc Sensors C Sensors

    Please remember to reattach the cover once the wires have been installed. NOTE! The AQ-01 point sensor does no not t come with a connection cable! © Arcteq Relays Ltd IM00009...
  • Page 33: Arc Light And Pressure Point Sensor Aq-02

    20 m, 25 m, 30 m, 35 m, 40 m, 45 m, 50 m). The fixed light intensity threshold of an AQ-07 sensor is 8,000 lux. The sensor does not require further settings by the user. The sensor's detection radius is 360 degrees. © Arcteq Relays Ltd IM00009...
  • Page 34: Arc Light Fiber Optic Loop Sensor Aq-08

    The covered area can be one (1) or two (2) meters by default; if other lengths are required, please consult the Arcteq sales team. You can find the "Contact and reference information" page at the end of this manual.
  • Page 35 (1) or two (2) meters of the fiber on each end. Please refer to the "Arc light fiber optic loop sensor AQ-07" chapter for more information. © Arcteq Relays Ltd IM00009...
  • Page 36: Sy Y St Stem Self-Super 6 S Em Self-Supervision Vision

    If at least one of the phases remains above 0.2 × I while the others are at zero, the unit issues an open CT alarm: the SF relay is released, the "Error" LED is turned on and the LED of the faulty phase(s) starts blinking. © Arcteq Relays Ltd IM00009...
  • Page 37: Applica A Tion Example

    When an arc fault occurs in a breaker or busbar compartment, the T3 trip contact of an AQ-110 can be used to trip the tie breaker. Alternatively, the T2 trip contact of an AQ101 or AQ-102 can be used to trip the tie breaker. © Arcteq Relays Ltd IM00009...
  • Page 38 A A Q Q -110x -110x Instruction manual Version: 2.01 Figure. 7 - 30. A main-tie-main application with AQ-100 series products. © Arcteq Relays Ltd IM00009...
  • Page 39: Connections

    The figures below depict the connections of AQ-110P and AQ-110F. Please note that the SF relay is in the de-energized position; also note that the unit has been halved for the image to allow for space for all connector explanations. Figure. 8 - 31. Rear terminals of AQ-110P. © Arcteq Relays Ltd IM00009...
  • Page 40: Outputs

    T4 is a common trip relay that operates whenever T1 or T2 operates. It can be used either for tripping one additional disconnecting device, or as a trip alarm in a (local or remote) monitoring and alarming system. © Arcteq Relays Ltd IM00009...
  • Page 41: Binary Outputs

    8.2 Inputs 8.2.1 Current measurement inputs Both AQ-110x variants have four (4) CT inputs for measuring the three phase currents and the residual current. Both the phase current and the residual current inputs can be configured to a nominal current of 1 A or 5 A with the DIP switches (for more information, please refer to the "DIP switch settings"...
  • Page 42: Binary Inputs

    The binary inputs are activated when a connected DC signal exceeds the specified nominal threshold level of the corresponding input. The nominal threshold level for AQ-110x units is 24 VDC. Please note that the actual activation of the binary input occurs earlier than the specified nominal threshold value (see Chapter 11.5, "Techical Data").
  • Page 43: Testing Esting

    10. Activate the camera flash within 30 cm (12 inches) of the point sensor unit but do not activate the binary input used for the overcurrent condition (I>). 11. Verify that no trip has occured and only the indicator LED of the sensor activation is lit. © Arcteq Relays Ltd IM00009...
  • Page 44: Testing The Cbfp Function

    If you want to have more information of these tests, please refer to the routine test reports sent with the AQ-110 unit and/or consult your nearest Arcteq representative for the type test reports.
  • Page 45: Test Plan Example

    A A Q Q -110x -110x Instruction manual Version: 2.01 9.5 Test plan example © Arcteq Relays Ltd IM00009...
  • Page 46: Tr R Oubleshoo 10 T Oubleshooting Ting

    A A Q Q -110x -110x Instruction manual Version: 2.01 10 Troubleshooting Table. 10 - 8. Troubleshooting guide for AQ-110x variants. P P r r oblem oblem P P ossible sol ossible solution( ution(s) s) Check the sensor's cable wiring (see the "Arc sensors" chapter for more information).
  • Page 47: Mounting And Installation

    Connector X2: Phoenix Contact FRONT-MSTB 2,5/15-STF-5,08 - connector type - wire cross section (min...max) 0.34...2.5 mm (24...12 AWG) - minimum stripping length 10 mm (0.39 in) - screw tightening torque (min...max) 0.5...0.6 N·m (4.4...5.3 lbf·in) © Arcteq Relays Ltd IM00009...
  • Page 48: Operating Times

    Overcurrent setting range: 0.5…6.0 × I - phase overcurrent - residual overcurrent 0.05…2.00 × I Measurement accuracy 10 % Rated AC burden (VA) 10 mΩ (input resistance) Power consumption of current input circuit < 10 mΩ © Arcteq Relays Ltd IM00009...
  • Page 49: Binary Inputs

    *) When the time constant L/R = 40 ms. 11.8 Binary output(s) Table. 11.8 - 17. Technical data for the relay binary output (BO1). Number of outputs Rated voltage +24 V DC Rated current (max.) 20 mA © Arcteq Relays Ltd IM00009...
  • Page 50: System Failure Relay

    Pressure measuring accuracy ±1.8 % (of full scale) Detection radius 180º Mechanical protection IP 20 Sensor cable specification Shielded twisted pair 0.75 mm (AWG: 18) Maximum sensor cable length (per channel) 200 m Operating temperature –20…+85 ºC © Arcteq Relays Ltd IM00009...
  • Page 51: Disturbance Tests

    –40…+125 ºC 11.11 Disturbance tests Table. 11.11 - 24. Technical data for the disturbance tests. Electromagnetic compatibility test CE-approved and tested according to EN 50081-2 and EN 50082-2 Conducted emission 0.15…30.00 Hz (EN 55011, class A) © Arcteq Relays Ltd IM00009...
  • Page 52: Voltage Tests

    Table. 11.15 - 28. Technical data for the device casing. Protection: - front IP 52 - back IP 20 Device dimensions (W × H × D) 102 × 177 × 161 mm Weight 1.2 kg © Arcteq Relays Ltd IM00009...
  • Page 53: Ordering Inf Dering Informa Ormation Tion

    A A Q Q -110x -110x Instruction manual Version: 2.01 12 Ordering information AQ-110P current measurement and arc sensing unit AQ-110F current measurement and arc sensing unit © Arcteq Relays Ltd IM00009...
  • Page 54 Accessories Order code Description Note Manufacturer AQX006 Wall mounting bracket For AQ-103 and AQ-110x variants (MV and LV). Arcteq Ltd. AQX016 Wall mounting bracket For AQ-101, AQ-101S and AQ-102 units (MV and LV). Arcteq Ltd. © Arcteq Relays Ltd IM00009...
  • Page 55: Contact And R Ence Informa Ormation Tion

    Arcteq Relays Ltd. Visiting and postal address Kvartsikatu 2 A 1 65300 Vaasa, Finland Contacts Phone: +358 10 3221 370 Website: arcteq.fi https://arcteq.fi/support-landing/ Technical support: +358 10 3221 388 (EET 8:00 – 16.00) sales@arcteq.fi E-mail (sales): © Arcteq Relays Ltd IM00009...
