- Page 1 Proprietary data, company confidential. All rights reserved. Confié à titre de secret d'entreprise. Tous droits réservés. Comunicado como segredo empresarial. Reservados todos os direitos. Confidado como secreto industrial. Nos reservamos todos los derechos.
-
Page 2: Table Of Contents
Content SCOPE OF DOCUMENT ............................ 3 GENERAL PRODUCT INFORMATION ......................3 : ............................... 3 RODUCT TYPE : ........................3 ANUFACTURER PPLICANT : ............................. 3 RAND RADEMARK : ......................3 ACTORY ANUFACTURING OCATION : ............................3 OUNTRY OF ORIGIN SYSTEM OVERVIEW ............................4 TCAM ....................... -
Page 3: Scope Of Document
1 Scope of Document The aim of this document is to provide a short overview on the Telematics Control Unit (TCP) of model G12N410G1 and G12N410M1 and to describe the TCP. 2 General Product Information Product type: Telematics Control Unit (TCP) -
Page 4: System Overview
ONSTAR is providing various connectivity services. 4 North America (NA) Variants TCP Model number TCP Variant NAD Model Number G12N410G1 TCP NA FE4NA0210 G12N410M1 TCP NA FE4NA0210 USER MANUAL Chap. -
Page 5: Mechanical Design
5 Mechanical design Pictures of the housing USER MANUAL Chap. 0 Version: GM OnStar Gen12 Fehler! Verweisquelle konnte Page 5 / 14 nicht gefunden werden. -
Page 6: Description Of The Tcp
6 Description of the TCP Product features The model main parts are: • NAD with 3G/4G/LTE and GNSS • External and internal antennas • Voice and Data • Glonass, Beidou, Galileo, GPS • 2x2 DL-MIMO for 4G • internal embedded Sim-IC •... -
Page 7: Wireless Services
Ethernet: Model number Speed G12N410G1 1 GB G12N410M1 100 MB Wireless services: ➢ 3G/WCDMA ➢ 4G/LTE ➢ VoLTE ➢ Voice/Assistance Calls o Emergency Calls o Assistance Calls o Calls are only possible to some fixed phone numbers ➢ Global Positioning and Navigation: GPS, GNSS, Beidou, Glonass ➢... -
Page 8: Connectors
Connectors The GM GEN12 TCP has 6 types (fully featured) of connectors (from left to right): ▪ X1: 20-Pin Main Signal Connector ▪ X2: 12-Pin Audio and 100BASET1 ▪ X6: Single RF: C-V2X-2 ▪ X3: Quad RF (Cellular PRIMARY, DRX0/GNSS, C-V2X-1) ▪... -
Page 9: X2 12-Pin Audio And 100Baset1 Connector Pin Out
6.5.2 X2 12-Pin Audio and 100BASET1 Connector Pin Out Signal Signal SPKR_P MIC_OUT_N SPKR_N MIC_OUT_P 100BT1_M MIC_OUT_N 100BT1_P MIC Shield MIC_OUT_P 6.5.3 X3 Quad RF Connector Signal GNSS/DRX0 V2X_1 DRX0 Primary LTE 6.5.4 X6 Single RF Connector Signal V2X_2 6.5.5 X7 1000BASET1 Connector Signal 1000BASET1+ 1000BASET1-... -
Page 10: Audio Subsystem
Audio Subsystem The TCU audio system will provide a hands-free user interface for emergency calls and call center concierge/personal calling within the vehicular environment. The audio system provides the following • Microphone front end input • Amplified speaker driver (class D amplifier) Keypad Subsystem The keypad subsystem will provide an interface between the user and the TCU for emergency calls and call center concierge/personal calling within the vehicular environment. -
Page 11: Technical Data
7 Technical data Operating temperature Range -40°C to 90°C Supply Voltage Nominal.: 12 V dc Supply Voltage Range: 8 V to 16 V dc Supply current consumption Typical standby current: 250mA (at 12 V) Typical active current consumption: 350mA (at 12 V) Maximum active current consumption: 600mA dc (at 12 V) Power Consumption Typical power consumption: 5.5W... -
Page 12: Wireless Services
8 Wireless services 3G/WCDMA: Wireless service: 3G/UMTS Band II (B2: 1900 UMTS): 1850-1910 / 1930-1990 MHz, Frequency bands / range: Band IV (B4: 1700 UMTS): 1710-1755 / 2110-2155 MHz, Band V (B5: 850 UMTS): 824-849 / 869-894 MHz Electrical output power: +23.0 dBm (+/- 1dB) 4G/LTE: Wireless service:... -
Page 13: Label Information
9 Label Information USA/Canada Model: G12N410G1 or G12N410M1 Contains FCC ID: LHJ-FE4NA0210 Contains IC: 2807E-FE4NA0210 10 Owner Manual Statements 10.1 Owner manual USA/Canada Continental Model: G12N410G1 or G12N410M1 Contains FCC ID: LHJ-FE4NA0210 Contains IC: 2807E-FE4NA0210 This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). - Page 14 FCC Class B digital device notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
