UTV Quad
Battery Powered Electric Ride-On
Owner's Manual
with Assembly Instructions
Made in China.
The owner's manual contains important safety information as well as assembly, use
and maintenance instructions. The Ride-on must be assembled by an adult who has
read and understands the instructions in this manual. Keep the packaging and bags
away from children and dispose of all packaging properly before use.
Keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTV Quad and is the answer not in the manual?

Questions and answers

Summary of Contents for TDC UTV Quad

  • Page 1 UTV Quad Battery Powered Electric Ride-On Owner’s Manual with Assembly Instructions Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on must be assembled by an adult who has read and understands the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging properly before use.
  • Page 3 Please contact us at our Toll Free customer service number 1-800-599-8898 for any assistance and replacement parts. Please keep your sales receipt which may be request when seeking assistance. Thank You. Dist. by TDC USA, Inc. Fairfield, NJ 07004 ©2021 All Rights Reserved. Made in China.
  • Page 4: Warranty Information

    If we verify a parts defect, we will repair or replace the part, yet you must pay for our labor to do so at our then current rates (if you do not re-install the part yourself). TDC USA INC. will not be responsible for shipping charges on received or refused packages, part returns, or scooter returns.
  • Page 5: Specifications

    Before You Begin Assembly • This ride-on car will provide your child with many miles of riding of enjoyment. To help assure you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference. •...
  • Page 6: Before You Begin Assembly

    Before You Begin Assembly BATTERY WARNINGS The following safety hazards may result in serious injury or death: • Use of a battery charger other than the supplied 12V rechargeable battery and charger may cause a fire or explosion. Only use the supplied battery and charger. •...
  • Page 7 Safety WARNING! PREVENT INJURIES AND DEATHS: NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. • Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
  • Page 8: Parts List

    Parts List PART NO. PART NAME QUANTITY (PCS) Vehicle Body Gear Box Front Wheel/Rear Wheel Ø12 Washer Lock Nut Hubcap Windshield Seat Rear Light Bar Rear Axle Steering Wheel M5X45 Machine Screw Ø5 Nut Charger Ø4x16 Screw Front Axle Hex Wrench Spanner Ø10 Plastic Washer (Not shown in parts diagram)
  • Page 9 Parts Diagram 5 14 1 1 7 1 1 8...
  • Page 10 Attach the Rear Shock Absorbers Rear bottom view Ø8 - plastic washer x 2 Fig. 1 Tools required: Hex Wrench x2 Rear bottom view Rear Axle frame Ø8 - plastic washer x 2 Fig. 2 Turn the vehicle body upside down 1.
  • Page 11 Attach the Rear Wheels Rear bottom view Rear axle frame Rear axle frame - Cut off the plastic ties on the rear axle frames with a scissors. - Release the gear boxes, - DO NOT disconnect the connectors of the gear boxes. 1.
  • Page 12: Front Bottom View

    Attach the Front Axle Turn the vehicle body upside down. 1.Remove the Lock Nut (5) and Ø12 Washer (4) on the Front Axle (16). Fit the Front Axle (16) to the front of the Vehicle Body (1) 2. Insert the bent end of the Steering Column into the hole on the Front Axle Linkage. Fit a Ø10 Plastic Washer (19) to the bent end of the Steering Column and insert a Split Pin (21) into the hole on the Steering Column, bend the ends of Split Pin (21) back using Long Nose Pliers (not...
  • Page 13 Attach the Front Wheel & Steering Wheel Front bottom view Front bottom view Turn the vehicle body upside down 1.Slide a Ø12 Washer (4) and a Front Wheel (3) onto the Front Axle (16). 2. Then slide a Ø12 Washer (4) onto the Front Axle (16). 3.
  • Page 14 Attach the Windshield & Rear Light Bar Fig. 7 1. Insert the tabs of the Windshield (7) into the holds on the Vehicle Body (1). Push until you hear it “snap” into place. 2. Insert two Ø4x16 Screws (15) through the Vehicle Body (1) and into the Windshield (7) and tighten with a Screwdriver.
  • Page 15 Attach the Seat & Connect the Power Supply 1. Align the slide strip under the Seat (8) with the slide way on the top of seat base, press the button located at the front of the seat base (Fig. 8) till the tabs on the back of Seat (8) inserted into the holes on the vehicle.
  • Page 16 Use your Ride On IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gears and motor. 1. Start Button: Turns vehicle on and off 2. Forward / Reverse Lever: Changes the direction that vehicle moves from forward to reverse 3.
  • Page 17 Charging • The POWER SWITCH must be turned in “OFF” position when charging. • Before the first use, you should charge the battery for 4-6 hours. Do not recharge the battery for more than 10 hours to avoid overheating the charger •...
  • Page 18 Charging Only An Adult Can Charge And Recharge The Battery! WARNING! PREVENT FIRE AND ELECTRIC SHOCK: • Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion.
  • Page 19: Battery Disposal

    Battery Replacement & Fuse The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 20 seconds and then turned ON again.
  • Page 20: Troubleshooting Guide

    Troubleshooting guide Problem Possible Cause Possible Cause Recharge battery. After each use, or once a month minimum, charge the battery for a ‘full’ 8 to 12 Battery low on power hours. DO NOT leave the battery on the charger for more than 20 hours.
  • Page 21 Maintaining • It is parents’ responsibility to check main parts of the toy before using. Regular examination of transformer or battery charger for any damage to their cord, plug, enclosure and other parts, and that, in the event of such damage, toy must not be used with the transformer or battery charger until such damage has been repaired.
  • Page 22 UTV Quad Battery Powered Electric Ride-On Dist. by TDC USA, Inc. Fairfield, NJ 07004 ©2021 All Rights Reserved. Made in China. Item #60621 Questions and Comments 1-800-599-8898 (9 am - 5 pm EST) www.tdcusainc.com This products meets ASTM F963 and CPSIA requirements for electric vehicles.
