4-Wheel Quad
Battery Powered Electric Ride-On
Owner's Manual
with Assembly Instructions
Made in China.
The owner's manual contains important safety information as well as assembly, use and
maintenance instructions. The Ride-on Car must be assembled by an adult who has read
and understands the instructions in this manual. Keep the packaging and bags away from
children and dispose of all packaging properly before use.
Keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4-Wheel Quad and is the answer not in the manual?

Questions and answers

Related Manuals for TDC 4-Wheel Quad

Summary of Contents for TDC 4-Wheel Quad

  • Page 1 4-Wheel Quad Battery Powered Electric Ride-On Owner’s Manual with Assembly Instructions Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.
  • Page 3 Please contact us at our Toll Free customer service number 1-800-599-8898 for any assistance and replacement parts. Thank You. Dist. by TDC USA, Inc. Fairfield, NJ 07004 ©2018 All Rights Reserved. Made in China.

  • Page 5: Year Limited Warranty

    1 YEAR LIMITED WARRANTY SIX MONTH LIMITED WARRANTY ON BATTERY 6-months warranty applies only to the 12-volt battery which is included by TDC USA Inc. with the vehicle when it was originally purchased. This warranty covers normal use and does not cover the vehicle or battery if damaged by unreasonable use, neglect, abuse, accident, misuse, improper service or other causes not arising out defects in material or workmanship.

  • Page 6: Before You Begin Assembly

    Before You Begin Assembly WARNING! · CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. · ADULT ASSEMBLY REQUIRED. · Always remove protective material and poly bags and dispose before assembly. •...

  • Page 7: Battery Warnings

    Before You Begin Assembly BATTERY WARNINGS The following safety hazards may result in serious injury or death: · Use of a battery charger other than the supplied 12V rechargeable battery and charger may cause a fire or explosion. Only use the supplied battery and charger. ·...

  • Page 8: Parts List

    Parts List PART NO. PART NAME QUANTITY (PCS) Vehicle body Driving wheel Front wheel Lock nut Split pin Hubcap Ø12 Washer Bushing Front axle Steering column Rear axle Seat rest Seat M5x12 machine screw Handle bar M5x30 machine screw Ø5 nut Ø4x12 screw Spanner Charger...

  • Page 9: Parts Diagram

    Parts Diagram Note: Some parts shown are assembled on both sides of vehicle...
  • Page 10 Attach the Front & Rear axle 1. Turn the vehicle body upside down. Remove all the parts from the rear axle. 2. Fit the Front axle (09) against to the front of the vehicle. 3. Tighten eight Ø4x12 machine screws (18) to secure the front axle to the vehicle with a screwdriver.
  • Page 11 Attach the Rear Wheels Rear bottom view Driving Wheel Rear axle (11) 1. Slide a Driving wheel (2) onto the Rear axle (11) 2. Slide the Ø12 Washer (7) onto the Rear axle. 3. Tighten a Lock nut (4) to the end of the Rear axle with a spanner. 4.

  • Page 12: Attach The Front Wheels

    Attach the Front Wheels Front Bottom View Front Wheel Front axle (9) 1. Remove all the parts from the front axle. 2. Slide a Bushing (8) onto the Front axle (9) 3. Slide a Front wheel (3) onto the Front axle. 4.
  • Page 13 Attach the Steering Column Hole in the front axle linkage 1. Turn the vehicle body on its side. 2. Insert the straight end of the steering column up through the hole in the front of the vehicle body from the bottom side and out through the hole in the dash. 3.
  • Page 14 Attach the Handle Bar 1. Turn the vehicle body over. 2. Remove the M5x30 machine screw (16) and Ø5 Nut (17) from the Handle Bar (15). 3. Place the Handle bar over the end of the Steering column. 4. Align the holes on each side of the Handle bar with the holes at the end of the Steering column.

  • Page 15: Connect The Power Supply

    Connect the Power Supply Rear Top View 1. Remove the Screw (14) on the top of the Seat (13) with a screwdriver. 2. Remove the Seat 3. Plug the Vehicle Connector into the Motor Connector. 4. Replace the Seat and Screw...
  • Page 16 Attach the Seat Rest 1. Fit the Seat rest (12) to the opening on the rear vehicle, and push until you hear it “click” into place.
  • Page 17 Safety WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
  • Page 18 Use your Ride On IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gears and motor. 1. Foot Pedal: Applies power (speed) to the vehicle. - To move the car press the pedal down. - To brake or slow down, release pressure from the pedal. 2.
  • Page 19 Charging 1. Plug the charger port into the input socket. (The socket is at the back of the vehicle) 2. Plug the charger plug into a wall outlet. The battery will begin charging WARNING! This product with Charging Safety Protection: when charging, all functions will be cut off! Only an adult can charge and recharge the battery!
  • Page 20 Charging Only An Adult Can Charge And Recharge The Battery! WARNING! · PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion.

  • Page 21: Battery Disposal

    Battery Replacement & Fuse The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 20 seconds and then turned ON again.

  • Page 22: Troubleshooting Guide

    Troubleshooting guide Problem Possible Cause Possible Cause Recharge battery. After each use, or once a month minimum, charge the Battery low on power battery for a ‘full’ 8 to 12 hours. DO NOT leave the battery on the charger for more than 20 hours.
  • Page 23 Maintaining • It is parents’ responsibility to check main parts of the toy before using. Regular examination of transformer or battery charger for any damage to their cord, plug, enclosure and other parts, and that, in the event of such damage, toy must not be used with the transformer or battery charger until such damage has been repaired.
  • Page 24 4-Wheel Quad Battery Powered Electric Ride-On Dist. by TDC USA, Inc. Fairfield, NJ 07004 ©2018 All Rights Reserved. Made in China. Item #91583 Questions and Comments 1-800-599-8898 (9 am - 5 pm EST) www.tdcusainc.com This products meets ASTM F963 and CPSIA requirements for electric vehicles.
