4. Adjustment
Use the tilt adjusting knobs to adjust your TV to the desired angle.
Maintenance
Check that the bracket is secure and safe to use at regular intervals
(at least every three months).
Please contact your local distributor if you have any questions.
SLT-510 manual.indd 2-3
Installation Instructions
Tilting Wall Mount
200x200 / 300x300
SLT-510
400x200 / 400x400
CAUTION: DO NOT EXCEED THE
MAXIMUM STATED WEIGHT CAPACITY.
SERIOUS INJURY OR PROPERTY
DAMAGE MAY OCCUR!
55"
MAX
70kg
10/08/12 1:23 PM
