40RU
Packaged Air-Handling Units
60 Hz
®
with Puron
(R-410A) Refrigerant
Sizes 25, 28, 30

TABLE OF CONTENTS

SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . 1
PRE-INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Moving and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rigging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Uncrating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unit Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unit Isolation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigerant Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chilled Water Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Fan Motors and Drives . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power Supply and Wiring . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
START-UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-34
Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fan Motor Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fan Shaft Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Centering Fan Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Shaft Position Adjustment . . . . . . . . . . . . . . . . . . . 22
Individual Fan Wheel Adjustment . . . . . . . . . . . . . . . . 22
Fan Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Pulley Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pulley and Drive Adjustment . . . . . . . . . . . . . . . . . . . . 23
Condensate Drains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chilled Water Coil Freeze Protection . . . . . . . . . . . . 23
Coil Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cleaning Cooling Coil . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cleaning Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Replacing Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . CL-1, CL-2
Installation, Start-Up and
Service Instructions

SAFETY CONSIDERATIONS

Improper
installation,
adjustment,
maintenance, or use can cause explosion, fire, electrical shock
or other conditions which may cause personal injury or
property damage. Consult a qualified installer, service agency,
or your distributor or branch for information or assistance. The
qualified installer or agency must use factory-authorized kits or
accessories when modifying this product. Refer to the
individual instructions package
Follow all safety codes. Wear safety glasses and work gloves.
Use quenching cloths for brazing operations and have a fire
extinguisher available. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult
local building codes and appropriate national electrical codes
(in USA, ANSI/NFPA70, National Electrical Code (NEC); in
Canada, CSA C22.1) for special requirements.
It is important to recognize safety information. This is the
safety-alert symbol
. When you see this symbol on the unit
and in instructions or manuals, be alert to the potential for
personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. These words are used with the
safety-alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or death.
WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe practices,
which may result in minor personal injury or product and
property damage. NOTE is used to highlight suggestions
which will result in enhanced installation, reliability, or
operation.
alteration,
service,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REFRIGERANT R-410A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carrier REFRIGERANT R-410A

  • Page 1: Table Of Contents

    40RU Packaged Air-Handling Units 60 Hz ® with Puron (R-410A) Refrigerant Sizes 25, 28, 30 Installation, Start-Up and Service Instructions TABLE OF CONTENTS SAFETY CONSIDERATIONS ..... . . 1 PRE-INSTALLATION .
  • Page 2: Pre-Installation

    ELECTRICAL SHOCK HAZARD Failure to follow this warning could cause personal injury or death. Before performing service or maintenance operations on unit, always turn off main power switch to unit and install lockout tag. Unit may have more than one power switch. UNIT OPERATION AND SAFETY HAZARD Failure to follow this warning could cause personal injury, death and/or equipment damage.
  • Page 3 TXV — Thermostatic Expansion Valve NOTES: 1. Dimensions in [ ] are in millimeters. 3. Recommended clearance: 4. Liquid piping not supplied by Carrier. 5. Duct flange is factory-supplied and field- Fig. 2A — Dimensions – Size 25 LEGEND Direction of airflow.
  • Page 4 • Right Side: 2 ft, 6 in. (762 mm) • Left Side: 2 ft, 6 in. (762 mm) • Local codes or jurisdiction may prevail. 4. Liquid piping not supplied by Carrier. 5. Duct flange is factory-supplied and field- installed. 6. 40RUS may require alternate or additional...
  • Page 5 Table 1A — 40RUA Physical Data, English — Cooling Units UNIT 40RUA* NOMINAL CAPACITY (Tons) OPERATING WEIGHT (lb) Base Unit with TXV Plenum FANS Qty...Diam. (in.) Nominal Airflow (cfm) Airflow Range (cfm) Nominal Motor Hp (Standard Motor) 208/230-3-60 and 460-3-60 575-3-60 Motor Speed (rpm) 208/230-3-60 and 460-3-60...
  • Page 6 Table 1B — 40RUA Physical Data, SI — Cooling Units UNIT 40RUA* NOMINAL CAPACITY (kW) OPERATING WEIGHT (kg) Base Unit with TXV Plenum FANS Qty...Diam. (mm) Nominal Airflow (L/s) Airflow Range (L/s) Nominal Motor kW (Standard Motor) 208/230-3-60 and 460-3-60 575-3-60 Motor Speed (r/s) 208/230-3-60 and 460-3-60...
  • Page 7 Table 1C — 40RUS Physical Data, English — Chilled Water Units UNIT 40RUS* NOMINAL CAPACITY (Tons) OPERATING WEIGHT (lb) Base Unit Plenum FANS Qty...Diam. (in.) Nominal Airflow (cfm) Airflow Range (cfm) Nominal Motor Hp (Standard Motor) 208/230-3-60 and 460-3-60 575-3-60 Motor Speed (rpm) 208/230-3-60 and 460-3-60 575-3-60...
  • Page 8 Table 1D — 40RUS Physical Data, SI — Chilled Water Units UNIT 40RUS* NOMINAL CAPACITY (kW) OPERATING WEIGHT (kg) Base Unit Plenum FANS Qty...Diam. (mm) Nominal Airflow (L/s) Airflow Range (L/s) Nominal Motor kW (Standard Motor) 208/230-3-60 and 460-3-60 575-3-60 Motor Speed (r/s) 208/230-3-60 and 460-3-60 575-3-60...
  • Page 9: Unit Positioning

    4 0 R U A A 2 5 A 1 A 6 _____________ Model Type 40RU = Carrier Fan Coil Puronr R--- 410A Refrigerant Type of Coil A = Standard DX Coil S = Chilled Water Coil Refrigerant Options A = None...
  • Page 10 OVERHEAD SUSPENSION ACCESSORY UNIT SIZE 25 UNIT SIZES 28, 30 NOTE: Dimensions in [ ] are millimeters Fig. 6 — Preferred Suspension Technique...
  • Page 11: Unit Isolation

    Unit Isolation — Where extremely quiet operation is essential, install isolators between floor and base of unit, or between ceiling and top section of unit. Be sure that unit is level and adequately supported. Use channels at front and sides of unit for reference points when leveling.
  • Page 12 UPPER SPLIT AIRFLOW LOWER SPLIT AIRFLOW LEGEND: – Not required when mated to units 38AP_025 - 060 TXV – Thermostatic Expansion Valve NOTE: Component location arrangemet shown for field installation of Fig. 8 — Face-Split Coil Suction and Liquid Line Piping (Typical) FIRST ON/LAST OFF = B VERTICAL INSTALLATION FIRST ON/LAST OF F = A...
  • Page 13 Table 2 — Factory-Installed Nozzle and Distributor Data COIL TYPE UNIT 40RU*25 4 Row 40RU*28 4 Row 40RU*30 4 Row † Feeder tube size is in. (6.35 mm). NOTE: Hot gas bypass applications require field-supplied auxiliary side connector. ACCESS UNIT ‡...
  • Page 14: Connection Type

    ACCESS UNIT ‡ HOLE NO. 40RUA28 40RUS*28, 30 40RUA*30 ‡ See Fig. 7 for access hole location by number. † Fittings are listed in order from header or tee stub connection out to access hole in corner support post. Table 3 — Fitting Requirement (cont) CONNECTION CIRCUIT TYPE...
  • Page 15: Chilled Water Piping

    40RUS unit size. To size, design, and install chilled water piping, consult the Carrier System Design manual. See Fig. 11 for an example of a typical installation. Recommended fittings are listed in Table 3. To access 40RUS coil vents and drains, remove the unit side panel over the coil header.
  • Page 16: Condensate Drain

    Condensate Drain — Install a trapped condensate drain line to unit connection as shown in Fig. 12. The unit drain con- nection is a PVC stub. See Fig. 13. Some areas may require an adapter to connect to either galvanized steel or copper pipe. For these applications, install a field-supplied threaded PVC adapter.
  • Page 17: Power Supply And Wiring

    Power Supply and Wiring — Check the unit data plate to ensure that available power supply matches electrical characteristics of the unit. Provide a disconnect switch with an integrated lock-out feature of size required to provide adequate fan motor starting current. See Tables 4-6 for unit electrical data.
  • Page 18: Fan Motor

    † UNIT V-PH-Hz 208/230-3-60 40RUA*25 460-3-60 40RUS*25 575-3-60 208/230-3-60 40RUA*28 460-3-60 40RUS*28 575-3-60 208/230-3-60 40RUA*30 460-3-60 40RUS*30 575-3-60 See Legend and Notes below. † UNIT V-PH-Hz 208/230-3-60 40RUA*25 460-3-60 40RUS*25 575-3-60 208/230-3-60 40RUA*28 40RUA*30 460-3-60 40RUS*28 40RUS*30 575-3-60 See Legend and Notes below. LEGEND —...
  • Page 19 EQUIP T’STAT NOTE: Use copper conductors only. Fig. 17 — Unit Wiring LEGEND — Equipment — Ground — Heating Contactor — Electric Heater — Indoor-Fan Contactor — Indoor-Fan Motor — Terminal Block — Thermostat Factory Wiring Field Control Wiring...
  • Page 20: Connecting Ductwork

    VOLTAGE 40RU** (vac) 25, 28, 30 Connecting Ductwork — Refer to the Carrier System Design Manual for the recommended design and layout of ductwork. Fig. 18 shows recommended duct connection to units with 2 fans. UNIT OPERATION HAZARD Failure to follow this caution could cause equipment damage.
  • Page 21: Start-Up

    START-UP Before starting unit, check the following and correct as necessary: • Is unit solidly supported? • Is fan adjusted for speed and pulley alignment? • Are pulleys, motor, and bearings securely mounted? • Are there any loose parts that will rattle or vibrate? •...
  • Page 22: Centering Fan Wheel

    Centering Fan Wheel — If fan and fan shaft assembly are not properly centered, blades may scrape against the blower side scroll plate or may create an objectionable whistling noise. It may be necessary to adjust individual fan wheels or move en- tire fan shaft.
  • Page 23: Fan Pulley Alignment

    Fig. 23 — Fan Rotation Fan Pulley Alignment — Align as follows: 1. Loosen setscrews on pulleys. 2. Align pulleys visually and tighten setscrews on fan pulley to lock it in place. 3. Use the methods shown in Fig. 24 to check proper pulley alignment.
  • Page 24: Replacing Filters

    Replacing Filters — Filters can be removed and in- stalled from either side of the unit. Install new filters in units that have one fan as follows: 1. Remove the side access panel (retain screws). 2. Remove the filter retainer clip (see Fig. 25). 3.
  • Page 25 Table 8A — Fan Motor Data, Standard Motor — English 40RUA*25 UNIT 40RUS*25 208/230-3-60 and 460-3-60 Speed (rpm) 1745 Frame (NEMA) S184T Shaft Dia (in.) 575-3-60 Speed (rpm) 1745 Frame (NEMA) 184T Shaft Dia (in.) LEGEND NEMA — National Electrical Manufacturers Association Table 8B —...
  • Page 26 Table 8C — Fan Motor Data, Standard Motor — SI 40RUA*25 UNIT 40RUS*25 208/230-3-60 and 460-3-60 Speed (r/s) 29.08 Shaft kW 3.73 Frame (NEMA) S184T Shaft Dia (mm) 28.6 575-3-60 Speed (r/s) 29.08 Shaft kW 3.73 Frame (NEMA) 184T Shaft Dia (mm) 28.6 LEGEND NEMA —...
  • Page 27 Table 9A — Standard Drive Data, 60 Hz — English UNIT MOTOR DRIVE Motor Pulley Pitch Diameter (in.) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (in.) Pulley Bore (in.) Belt No. — Section Belt Pitch (in.) FAN SPEEDS (rpm) Factory Setting Range...
  • Page 28 Table 9C — High-Static Drive Data, 60 Hz — English UNIT MOTOR DRIVE Motor Pulley Pitch Diameter (in.) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (in.) Pulley Bore (in.) Belt No. — Section Belt Pitch (in.) FAN SPEEDS (rpm) Factory Setting Range...
  • Page 29 Table 9E — Medium-Static Drive Data, 60 Hz — SI UNIT MOTOR DRIVE Motor Pulley Pitch Diameter (mm) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (mm) Pulley Bore (mm) Belt No. — Section Belt Pitch (mm) FAN SPEEDS (r/s) Factory Setting Range...
  • Page 30 Table 10A — 40RU Standard Fan Performance Data — 0.0-2.4 in. wg External Static Pressure — English AIRFLOW UNIT (Cfm) 6,000 1.25 7,000 1.93 40RUA*25 8,000 2.83 40RUS*25 9,000 3.97 10,000 5.38 7,500 1.29 8,750 1.98 10,000 2.88 40RUA*28 40RUS*28 11,250 4.03 12,500...
  • Page 31 Table 10B — 40RU Standard Fan Performance Data — AIRFLOW UNIT (L/s) 2830 8.86 0.94 3300 10.14 1.44 40RUA*25 3780 11.43 2.11 40RUS*25 4250 12.74 2.96 4720 14.05 4.01 3540 7.60 0.96 4130 8.68 1.47 40RUA*28 4720 9.78 2.15 40RUS*28 5310 10.89 3.01...
  • Page 32 Table 10C — 40RU High-Capacity Fan Performance Data — 0.0-2.4 in. wg External Static Pressure — English AIRFLOW UNIT (Cfm) 6,000 1.29 7,000 1.99 40RUA*25 8,000 2.92 40RUS*25 9,000 4.10 10,000 5.56 7,500 1.39 8,750 2.14 40RUA*28 10,000 3.12 40RUS*28 11,250 4.37 12,500...
  • Page 33 Table 10D — 40RU High-Capacity Fan Performance Data — AIRFLOW UNIT (L/s) 2830 9.03 0.96 3330 10.34 1.48 40RUA*25 3780 11.67 2.17 40RUS*25 4250 13.01 3.05 4720 14.36 4.15 3540 7.94 1.04 4130 9.08 1.59 40RUA*28 4720 10.24 2.33 40RUS*28 5310 11.42 3.26...
  • Page 34 3. Refer to fan motor and drive tables for additional data. Copyright 2009 Carrier Corp • 7310 W. Morris St. • Indianapolis, IN 46231 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
