Recommended Operating Conditions; Power Consumption - Arduino Portenta X8 Product Reference Manual

Rating

4 Recommended Operating Conditions

Symbol Description
V
Input voltage from VIN pad
IN
V
Input voltage from USB connector
USB
V
3.3 V output to user application
3V3
I
3.3 V output current available for user application
3V3
V
Input high-level voltage
IH
V
Input low-level voltage
IL
I
Current at VDD-0.4 V, output set high
OH Max
I
Current at VSS+0.4 V, output set low
OL Max
V
Output high voltage, 8 mA
OH
V
Output low voltage, 8 mA
OL

5 Power Consumption

Symbol Description
P
Power consumption with busy loop
BL
P
Power consumption in low power mode
LP
P
Maximum Power Consumption
MAX
It is recommended to use a USB 3.0 port when connecting to the Portenta X8 which can deliver the required power.
Dynamic scaling of the Portenta X8 can change the current consumption, leading to current surges during bootup.
Average power consumption is provided in the above table for several reference scenarios.
8 / 21 Arduino® Portenta X8
Arduino® Portenta X8
Min Typ
4.5 5
4.5 5
3.1
- -
2.31 -
0 -
2.7 -
0 -
Min Typ Max
2350
200
4000
Modified: 25/03/2022
Max Unit
5.5 V
5.5 V
V
1000 mA
3.3 V
0.99 V
8 mA
8 mA
3.3 V
0.4 V
Unit
mW
mW
mW
