INSTRUCTION SHEET
ADJUSTING THE T-TYPE AND FLIP BACK
ARMRESTS
This document explains how to adjust the removable T-Type armrests and the removable and retractable flip back armrests
on Motion Composites folding and rigid wheelchairs.
For information on how to remove, install, tilt or adjust the height of an armrest, refer to the User's Manual.
Wheelchair model(s)
•
HELIO C2/XC2/A6/A7/Kid/K
•
VELOCE
•
APEX A/C/P
R
EMINDER
Removable T-Type armrests (shown with 14" long pads or full length pads).
•
Three sorts of T-Type armrests are available for folding and rigid chairs:
•
Standard armrest with push-button height adjustment mechanism
•
Standard armrest with bidirectional lateral button height adjustment mechanism
•
Small armrest with button height adjustment mechanism
•
Standard push-button
Removable, retractable flip back armrest (shown with 14"
•
long pads or full length pads)
Possibility to convert it into a T-Type armrest
•
•
Armrest type not available for APEX line of rigid
wheelchairs
MC-MTKG-WI-0009
•
CHRONOS
•
PLATINUM 1/2
•
COBALT 1/2
Standard bidirectional lateral button
Last revision: 2021-09-07
Tool(s) and materials required
•
Hexagonal key (Allen key): 2 mm, 4 mm
•
Medium or small flat or star (Phillips) head screwdriver
Small push-button
Page 1 of 4
Advertisement
Table of Contents
Related Manuals for Motion Composites HELIO C2
Summary of Contents for Motion Composites HELIO C2
- Page 1 This document explains how to adjust the removable T-Type armrests and the removable and retractable flip back armrests on Motion Composites folding and rigid wheelchairs. For information on how to remove, install, tilt or adjust the height of an armrest, refer to the User's Manual.
- Page 2 (4) set screws • Contact your sales representative or the Motion Composites Customer Experience Team to order the appropriate parts * Receiver model introduced in September 2021 gradually in the different markets. The offer depends on the model of the wheelchair...
- Page 3 INSTRUCTION SHEET ADJUSTING THE T-TYPE AND FLIP BACK ARMRESTS HANGING THE REMOVAL MODE FIXED OR REMOVABLE OF A FLIP BACK ARMREST • Raise the armrest all the way up to access the screw installed on the double hook trigger (red plastic part) of the pivot arm •...
- Page 4 INSTRUCTION SHEET ADJUSTING THE T-TYPE AND FLIP BACK ARMRESTS ONVERTING A FLIP BACK ARMREST INTO A YPE ARMREST • To convert a removable and retractable flip back armrest into a T-Type armrest, simply remove the pivot arm. Refer to the User's Manual (folding wheelchairs) •...
