INSTRUCTION SHEET
SEAT SLING INSTALLATION (APEX A - APEX C – APEX P)
•
As many straps as possible should always be installed on the wheelchair and keep the remaining ones in
case of a future modification of the wheelchair (see tables below).
•
IF THE MINIMUM NUMBER OF STRAPS CANNOT BE INSTALLED, REMOVE ONE OR MORE ACCESSORIES.
•
The 10'' and 11'' deep seat slings are incompatible with T armrests and side guards.
•
Before beginning assembly, make sure you have all the necessary parts. These parts must be ordered through your
representative or through the Moton Composites customer service. Make sure to have the serial number of your
wheelchair to make ordering easier.
Material(s) required:
•
1 X Seat strap kit 1'' – assy (#9008113A)
INSTALLATION
1.
Insert the strap into the clamps on each side of the
Velcro.
•
It is important to ensure that the stap is
inserted correctly into the slots of the
clamp.
Revision date: 17/08/2022
Tool(s) required:
•
None
2.
Install the clamps (with straps) on the wheelchair
H-Block wherever space permits.
3.
Pass the strap through the eyelet on the opposite
side.
MC-MKTG-WI-0043
1
