SWIMMING POOL PUMP
Vertical Discharge:
Horizontal Discharge:
Aquatools
600 S. Jefferson Street, Waterford, WI 53185
North America: 800-752-0183, FAX 800-582-2217
International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245
© 1995, Printed in U.S.A
O
W N E R '
INSTALLATION, OPERATION & PARTS
MODELS
3/4 HP
AT240701
AT240702
AT240703
AT230701
AT230702
AT230703
S
M
A
N
U
779 0294
1 HP
1-1/2 HP
AT241001
AT241501
AT241002
AT241502
AT241003
AT241503
AT231001
AT231501
AT231002
AT231502
AT231003
AT231503
This manual should be furnished to
the end user of this pump; its use
will reduce service calls and chance
of injury and will lengthen pump life.
A
L
AT333 (1/18/95)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT240701 and is the answer not in the manual?

Questions and answers

Summary of Contents for AquaTools AT240701

  • Page 1 SWIMMING POOL PUMP W N E R ’ 779 0294 INSTALLATION, OPERATION & PARTS MODELS 3/4 HP 1 HP 1-1/2 HP Vertical Discharge: AT240701 AT241001 AT241501 AT240702 AT241002 AT241502 AT240703 AT241003 AT241503 Horizontal Discharge: AT230701 AT231001 AT231501 AT230702 AT231002 AT231502...
  • Page 2: Table Of Contents

    (1) year from date of installation. The foregoing warranties relate to the original consumer purchaser (“Purchaser”) only. Aquatools shall have the option to repair or replace the defective product, at its sole discretion. Purchasers must pay all labor and shipping charges necessary to replace the product covered by this warranty.
  • Page 3: Safety Instructions

    • Check all clamps, bolts, lids, and system accessories before testing. • Release all air in system before testing. • Tighten Aquatools trap lids to 30 ft. lbs. (4.1 kg-cm) torque for testing. • Water pressure for test must be less than 25 PSI (172 kPa).
  • Page 4: Specifications/Dimensions

    SPECIFICATIONS/DIMENSIONS 23.08 7.47 (190) (586) 10.12 (257) Ø6.81 4.00 1-1/2" NPT (Ø173) (102) Discharge Port Union Connection 1-1/2" NPT Suction 8.31 (211) 4.25 15.31 (108) (389) 13.09 11.50 (333) 10.69 (292) (272) 7.00 (178) 4.50 8.00 (114) (203) 781 0294 6.09 17.08 (155)
  • Page 5 Pump Model Motor Voltage/ Full Load Circuit Breaker H.P. Hz/Phase Amps Rating(Amps) AT230701, AT240701, AT230703, AT240703 115/60/1 AT231001, AT241001, AT231003, AT241003 115/60/1 11.2 AT231501, AT241501, AT231503, AT241503 1-1/2 115/60/1 16.0 NOTICE: Values given in table above are for pump motor only. Add the amp draw for any addi- tional accessories installed on pump motor circuit (heater, blower, etc.) to the listed amp ratings...
  • Page 6: Installation

    Trap Lid 1-1/2" Discharge Port 1-1/2" NPT Suction Port Return Line To Pool Skimmer 780 0294 Pool To Separation Tank Water or Waste INSTALLATION Pool Drain Line Locate pump as close to pool as possible and not more than 3 feet above pool Figure 2: Typical Pump/Filter water level.
  • Page 7 Teflon Taping Instructions: • Use only new or clean PVC pipe fittings. • Wrap male threads with one or two layers of teflon tape, winding tape clockwise as you face the start of the thread. Cover entire threaded portion of pipe (see Figure 5). •...
  • Page 8: Electrical

    ELECTRICAL Plug pump into a grounded, GFCI-protected 115 Volt circuit only. Incorrect voltage can cause fire or seriously damage motor and voids warranty. Risk of electrical shock. Connect only to a grounded type re- ceptacle protected by a ground-fault circuit-interrupter (GFCI). GFCI tripping indicates an electrical problem.
  • Page 9: Pump Service

    In a flooded suction system (water source higher than pump), pump will prime itself when suction and discharge valves are opened. If pump is not in a flooded suction system, unscrew and remove trap cover (see Figure 8); fill trap and pump with water. Clean and inspect “O”...
  • Page 10 5. Remove cap screws (Key No. 16, Page 12) from front plate (Key No. 13). Remove front plate with trap (Key No. 20) attached. Remove and inspect O-Ring (Key No. 12). 6. Remove end cap from motor cover. 7. Hold motor shaft with screwdriver in slot in end of motor shaft or 7/16” wrench on flats on motor shaft;...
  • Page 11: Storage/Winterizing

    STORAGE/WINTERIZING Pool/spa chemicals may give off corrosive fumes. Store chemicals away from system in a well ventilated area. NOTICE: Allowing pump to freeze will damage pump and void warranty. Drain all water from pump and piping when expecting freezing temperatures or when storing pump for a long time (see instructions below).
  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING GUIDE 2. CIRCUIT BREAKER IN HOME PANEL TRIPS RE- Read and understand safety and operating instruc- PEATEDLY tions in this manual before doing any work on pump. A. Circuit: Only qualified personnel should electrically test 1. Breaker must be of adequate capacity. pump motor.
  • Page 13: Repair Parts List

    REPAIR PARTS LIST POOL PUMPS 3/4 through 1-1/2 HP Models Ending in 02 NOTICE: AT23 series models use the same front plate and seal plate as other models; however, they are rotated 90° counter-clockwise when installed. Part Description Qty. Number End Cap Screw 37337-0085 782 0294...
  • Page 14 Purchase optional AT230701 AT231001 AT231501 union packages: AT230703 AT231003 AT231503 WC198-105 – 1-1/2” NPT See box C198-3 – 1-1/2” Slip AT240701 AT241001 AT241501 at right Each package includes AT240703 AT241003 AT241503 1 each: Collar, adapter, and O-Ring. NOTICE: AT23 series models use the same front plate and seal plate as other models;...
