CORD CONNECTED
SWIMMING POOL PUMP
O
W N E R '
INSTALLATION, OPERATION & PARTS
3/4 HP
AT240701
AT230701
S
M
A
N
MODELS
1 HP
1-1/2 HP
AT241001
AT241501
AT231001
Printed in U.S.A.
U
A
L
This manual should be furnished to
the end user of this pump; its use will
reduce service calls and chance of
injury and will lengthen pump life.
AT331 (Rev. 7/22/94)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AquaTools AT240701
Summary of Contents for AquaTools AT240701
- Page 1 Aquatools 600 S. Jefferson Street, Waterford, WI 53185 North America: 800-752-0183, FAX 800-582-2217 International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245 © 1994, Aquatools Printed in U.S.A. AT331 (Rev. 7/22/94)
-
Page 2: Table Of Contents
LIMITED WARRANTY Pumps, filters, spa systems, skimmers, underwater lights (except bulbs), accessories and fittings manufactured by Aquatools are warranted to be free of defects in material and workmanship for one (1) year from date of in- stallation. The foregoing warranties relate to the original consumer purchaser (“Purchaser”) only. Aquatools shall have the option to repair or replace the defective product, at its sole discretion. -
Page 3: Safety Instructions
• Release all air in system before testing. tric supply; provide a properly located outlet. • Tighten Aquatools trap lids to 30 ft. lbs. (4.1 kg-m) torque for testing. • Water pressure for test must be less than 25 PSI (7.5 kg/cm This pump is for use •... -
Page 4: Specifications/Dimensions
Wire Gauge Size Model Motor Voltage/ Full Load Circuit Breaker Dist. in Ft. (M)-Service Motor Temp. H.P. Hz/Phase Amps Rating (amps) Rating-°C 0-100’ (0-30) 101-200’ (31-60) 201-300’ (61-90) AT240701 115/60/1 AT230701 115/60/1 AT241001 115/60/1 11.2 AT231001 115/60/1 11.2 AT241501 1-1/2 115/60/1 16.0... -
Page 5: Installation
Strainer Basket Cover " NPT Discharge Port " NPT Suction Port Return Line To Pool 764 0294 Skimmer Drain Plug Figure 2 Pool To Separation Tank Water or Waste INSTALLATION Pool Drain Line Installation and wiring of pump should only be done by qualified, Figure 3: Typical Pump/Filter licensed personnel. - Page 6 Teflon Taping Instructions Use only new or clean PVC pipe fittings. Wrap male pipe thread with one or two layers of teflon tape, winding tape clockwise as you face the start of thread. Cover entire thread por- tion of pipe. See Figure 6. If leaks occur, remove pipe, clean off old tape, rewrap with one to two additional layers of tape and remake the connection.
-
Page 7: Electrical
ELECTRICAL Ground motor before connecting to electrical power supply! Failure to ground pump motor can cause serious or fatal electrical shock hazard! Do not ground to a gas supply line! To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. -
Page 8: Operation
OPERATION NEVER run pump dry! Running pump dry may damage seals, causing leakage and flooding! Fill pump with water before starting motor. Do not add chemicals to pool/spa system directly in front of pump suc- tion. Adding undiluted chemicals may damage pump and voids warranty. -
Page 9: Pump Service
PUMP SERVICE Pump should only be serviced by qualified personnel. Be sure to prime pump (Page 8) before starting. Before removing trap cover or front plate bolts: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. -
Page 10: Storage/Winterizing
STORAGE/WINTERIZING To prevent damage to components from fumes, store pool and spa chemicals away from pump and spa. If possible, store chemicals in an other well-ventilated area. Allowing pump to freeze will damage pump and void warranty! Drain all water from pump and piping when expecting freezing temper- atures or when storing pump for a long time (see instructions below). -
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE D. CIRCUIT BREAKER IN HOME PANEL Read and understand safety and operating in- TRIPS REPEATEDLY structions in this manual before doing any work on pump! 1. Breaker must be of adequate capacity. 2. For GFCI breaker; test according to GFCI manufac- Only qualified personnel should electrically test turer’s instructions. -
Page 12: Repair Parts List
(Key No. 8) Cord & Plug Assembly 115Volt (20 amp-1-1/2 HP Only) U117-1118 AT230701 AS900DLL C105-228PHS • Nameplate U33-155 • Decal-”Use Copper AT240701 AS900DLL C105-228PHS Conductors Only. . .” U27-635 AT231001 AS900ELL C105-228PGS • Warning Tag C63-12 AT241001 AS900ELL C105-228PGS •...
