- Page 1 ® FreeSpace Model 32SE Surface-Mount Environmental Loudspeaker Service Manual © 2006 Bose Corporation Part Number 257200 Rev. 01...
-
Page 2: Table Of Contents
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT BY AN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR USED FOR ANY OTHER PURPOSE. WARRANTY The Bose Model 32SE Loudspeaker is covered by a five-year limited warranty. -
Page 3: Specifications
SPECIFICATIONS External Dimensions: Single Speaker: 9.12" x 6" x 5.6" (23 cm x 15 cm x 14 cm) Packed System: 7.3" x 14.2" x 10.3" (18.5 cm x 36.1 cm x 26.2 cm) Weight: Single Speaker: 5.0 lb (2.3 kg) Packed System: 11.0 lb (5 kg) Transducer Complement:... -
Page 4: Disassembly/Assembly Procedures
This can be accomplished by inserting the ® hook portion of a scribe or your fingers into 2.1 Make sure that the Bose logo on the nameplate (1) is facing the same way as the ports and using this as a grasping area the print on the back of the cabinet (6). - Page 5 DISASSEMBLY/ASSEMBLY PROCEDURES 7. Crossover Assembly Removal 10.3 Secure the terminal strip to the rear of (passive variation) the cabinet (6) using the two screws (14) removed in step 9.1. Make sure the gasket 7.1 Perform procedure 5. is aligned properly to provide an airtight seal.
-
Page 6: Test Procedures
TEST PROCEDURES 1. Phase Test 3.2 Listen for any rubbing or ticking noise from the driver. Replace any driver that is Note: Perform the Phase Test on the defective. 4 Ohm passive variation of the Model 32SE Note: There is a normal suspension noise. loudspeaker only. -
Page 7: Main Part List, Model 32Se Loudspeaker (See Figures 2 And 3)
MAIN PART LIST Model 32SE Loudspeaker (see Figures 2 and 3) Item Description Part Number Qty. per Note Number Pair NAMEPLATE, LOGO, MD 32SE, BLK 252414-001 NAMEPLATE, LOGO, MD 32SE, WHT 252414-002 GRILLE, METAL, BLACK 278049-1 GRILLE, METAL, ARCTIC WHITE 278049-2 SCREW, TAPP, 8-11.75, PAN, ASY, SQ 290306-12... - Page 8 RED WIRE FROM POSITIVE LEAD ON TERMINAL CONNECTOR (4x) 15 See Figure 4 (2x) RED WIRE (2x) TO POSITIVE TERMINAL ON DRIVER (2x) (9x) Figure 3. Model 32SE Loudpeaker Exploded View (Passive Variation)
-
Page 9: Electrical Part List, Crossover Assembly, Passive Variation (See Figure 4)
ELECTRICAL PART LIST Crossover Assembly, Model 32SE Loudspeaker Passive Variation (see Figure 4) Item Description Part Number Note Number 5.1 OHM, WW, 5W, 10% 125605-5R1 5.0uF, EL, BP, 85C, 50V, 10% 291092-001 1.5mH 293529-001 INDUCTOR ONLY, NO HARDWARE SCREW, MACH, 6-32, PAN, XREC 181701-01 WASHER, FENDER, NON MAG 181700-01... -
Page 10: Packaging Part List, Model 32Se Loudspeaker (See Figure 5)
PACKAGING PART LIST Model 32SE Loudspeaker (see Figure 5) Item Description Part Number Note Number BRACKET, MOUNTING, BLK 178098-1 BRACKET, MOUNTING, WHT 178098-2 HARDWARE KIT, ENV., BLK 290853-001 70/100V HARDWARE KIT, ENV., WHT 290853-002 70/100V HARDWARE KIT, ENV., BLK 290307-001 PASSIVE HARDWARE KIT, ENV., WHT 290307-002... - Page 11 SERVICE MANUAL REVISION HISTORY Date Revision Description of Change Change Driven Pages Level Affected 06/00 Document release revision 00 Service manual release 02/06 00 to 01 Added RoHS part numbers This product is 6,8,9 now built with RoHS compliant parts.
- Page 12 SPECIFICATIONS AND FEATURES SUBJECT TO CHANGE WITHOUT NOTICE Bose Corporation The Mountain Framingham Massachusetts USA 01701 P/N: 257200 Rev. 01 1/06 FOR TECHNICAL ASSISTANCE OR PART ORDERS, CALL 1-800-223-4408...
