De La Rosa Research 31202A User Manual

Hide thumbs Also See for 31202A:
Table of Contents

Advertisement

Quick Links

Download this manual
LINEAR MOVEMENT
APPARATUS
USER´S
MANUAL
Model
31202A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 31202A and is the answer not in the manual?

Questions and answers

Related Manuals for De La Rosa Research 31202A

Summary of Contents for De La Rosa Research 31202A

  • Page 1 LINEAR MOVEMENT APPARATUS USER´S MANUAL Model 31202A...
  • Page 2 There you will find all related information for correct handling and usage of this product. We hope that you enjoy using this equipment as much as we did creating it. De la Rosa Research Team.
  • Page 3 Pag. Details Pag. Specifica�on Pag. Applica�ons Pag. Features Pag. Procedure...
  • Page 4 DETAILS The Linear Movement Apparatus c an be used for motor learning tasks and assessing temporal or spa�al memory . This device has been used in motor learning and neuroscience s tudies, and motor skill evalua�on. The Linear Movement Apparatus consis ts of an op�cal encoder that accurately measures the swit ch displacement.

  • Page 5: Specifications

    SPECIFICATIONS Line Voltage: 110/220 V AC - 50/60 Hz. Current: 10 Amps. Heigh: 10.4” // Wide: 5.3” // Depth: 46.8” Weight: 11 kg Aprox. Accuracy: 1mm-0.5mm Supplied with User Guide.
  • Page 6 APPLICATIONS The syst em measures �me es�ma�on, speed and distance; basic for avia �on personnel, professional drivers and high performance athletes.
  • Page 7 FEATURES Recyclable materials...
  • Page 8 FEATURES PRECISION SWITCH ON SLIDE High rated contact switch for long lasting usage HANDLE Ergonomic handle for easy carrying. BODY MATERIALS Aluminum - stainless steel, HDPE and acrylic Built from high-quality components body for sturdy usage.High resistance manufactured in USA, Japan, Italy, (and 100% recyclable) polymer base, easy and Colombia among others to clean.
  • Page 9 FEATURES USB PORT RULE USB port for serial communication Distance guide rule (the software will be available and supplied at no charge). LCD CONTROL POWER SUPPLY LCD and key pad controlEasy vailable for 110 V and to read LCD displayAllows 220V countries.
  • Page 10 PROCEDURE General recommendations Initial settings Operating...

  • Page 11: General Recommendations

    PROCEDURE // GENERAL RECOMMENDATIONS WARNING Avoid using sharp objects Always ensure the proper with the product. power input. Before you plug in the equipment be sure that the electric supply of your country or region is the right one to operate the Protect the product from Do not try to fix or equipment.
  • Page 12 PROCEDURE // GENERAL RECOMMENDATIONS Place the LCD control away from the subject to prevent SUBJECT EXPERIMENTER him/her to see the informa�on displayed. The subject must be standing and in a manner that does not see the rule, this may only Be seen by the experimenter.

  • Page 13: Initial Settings

    PROCEDURE WHAT SHOULD // INITIAL SETTINGS BE INCLUDED IN THE PACKAGE? Depending on the geographical area, you will be given one of these AC cables (one per package). a. Linear Movement Apparatus body x1 // b. LCD Control x1// Serial cable DB25 x 1 // d.

  • Page 14: Ac Power Cable

    PROCEDURE HOW TO ASSEMBLE IT? // INITIAL SETTINGS USB CABLE USE ONLY IF CONTROL SOFTWARE IS AVAILABLE POWER CABLE. The smallest end B of the USB cable (f) should be connected to this port. The opposite end of cable A should be Connect the A/C cable The opposite end should be connected to a 110/220VAC- 50/60Hz power outlet.
  • Page 15 3” 4” DOWNLOAD THE CABLE CONNECTION SOFTWARE SET UP SOFTSUITE2 MAIN LCD CONTROL Check the computer installation requirements before installation: Connect the main LCD control to the main unit using the corresponding (e) DB25 to USB 3.0 cable connector. Technical requirements SoftSuite2 •...
  • Page 16 AC POWER CABLE TURNING ON Connect the AC power cable (g) Before turning the equipment On. Please verify that all the cables are connected correctly. Please, double check that the AC power Cable is safely and securely plugged to both the main unit and the AC wall outlet. Also, check that all the cables are set accordingly to the previous steps.
  • Page 17 END THE CONNECTION USB Cable Connect the USB B connector of the provided USB Cable to the main unit, then connect the USB A connector to a computer's USB port. At this point you must have the SoftSuit2 software installed on your computer, considering that you are going to use any of its functions.

  • Page 18: What Does It Mean

    PROCEDURE WHAT DOES IT MEAN? // INITIAL SETTINGS S means SPEED and refers the calculated speed of the distance over �me. D means distance. Distance can be either posi�ve or nega�ve from the beginning point, indica�ng direc�on. Distance is given in tenths of millimeters (1/10).
  • Page 19 WHAT IS THE FIRST THING I SEE IN CONTROL SELECTING TEST WHEN THE EQUIPMENT IS TURNED ON? Starting a test. Introduction A total of 10 tests (trials) can be selected using the “UP” and “DOWN” keys. De la rosa Dlrr - 31202 D : 0 S : 0 research...
  • Page 20 PROCEDURE SELECTING TEST WHAT DO YOU DO WHEN A Finish a test. // OPERATING TEST ENDS? Use a spreadsheet on your computer or a sheet of paper and write down the results obtained in the test. D : 55.53 S : 0.015 T : 3696 TS : 2 You can see the final distance and the final...
  • Page 21 HOW TO LAUNCH VIRTUAL VIRTUAL LCD CONTROL / CONTROL PANEL LCD CONTROL? Then read the information displayed and enter the LCD Control panel. Introduction VIRTUAL LCD CONTROL / START To launch the virtual lcd control, select the button located in the left bar menu and then wait a few seconds. LCD CONTROL PANEL 1.
  • Page 22 VIRTUAL LCD CONTROL / DO THE TEST VIRTUAL LCD CONTROL / AT THE END OF A TEST Press the button (2) "Start / Stop" to start a test, follow the instructions shown, the test will At the end of the test you will be able to check the results. Use your computer screen shot or start when the system prompts you to hold the sensor.
  • Page 23 VIRTUAL LCD CONTROL / NEW TEST VIRTUAL LCD CONTROL / CLOSE To select another workspace use the (3) "Up" and (4) "Down" buttons. To close the virtual lcd control, press the upper right button. There are 10 workspaces, if you need to perform more than 10 tests, you must overwrite a previous workspace.
  • Page 24 We will be very happy to hear from you. support@delarosaresearch.com (+57) 1 6151702 (+57) 3003642343 Cll 147 A # 48 - 08. Bogotá, Colombia De la Rosa Research Team. MIAMI: 2550 NW 72ND AVE Bogotá, Colombia SUIT 115 COD. 8883. USA Cll 147A # 48-08 Bogotá, D.C.
