- Page 1 LINEAR MOVEMENT APPARATUS USER´S GUIDE Model 31202A...
- Page 2 There you will find all related information for correct handling and usage of this product. We hope that you enjoy using this equipment as much as we did creating it. De la Rosa Research Team.
- Page 3 Pag. Details Pag. Specifica�on Pag. Applica�ons Pag. Features Pag. Procedure...
- Page 4 DETAILS The Linear Movement Apparatus can be used for motor learning tasks and assessing temporal or spa�al memory. This device has been used in motor learning and neuroscience studies, and motor skill evalua�on. The Linear Movement Apparatus consists of an op�cal encoder that accurately measures the switch displacement.
-
Page 5: Specifications
SPECIFICATIONS Line Voltage: 110/220 V AC - 50/60 Hz. Current: 10 Amps. Materials: stainless steel, aluminum, HDPE, and plexiglass Dimensions (H x W x D): 12” X 10” X 47” Current: 2 amps / 220 - 110Volts 60 Hz Heigh: 11” // Wide: 10” // Depth: 27” Weight: 11 kg approx. - Page 6 APPLICATIONS The system measures �me es�ma�on, speed and distance; basic for avia�on personnel, professional drivers and high performance athletes.
- Page 7 FEATURES Recyclable materials...
- Page 8 FEATURES BODY HANDLE Aluminum - stainless steel, HDPE and Ergonomic handle for easy carrying. acrylic body for sturdy usage. High resistance (and 100% recyclable) polymer base, easy to clean. PRECISION SWITCH ON SLIDE High rated contact switch for long lasting usage...
- Page 9 FEATURES USB PORT USB port for serial communication (the software will be available and supplied at no charge). POWER SUPPLY Available for 110 V and 220V countries. LCD CONTROL MATERIALS LCD and key pad control Built from high-quality components Easy to read LCD display manufactured in USA, Japan, Italy, Allows distance and time measurements.
- Page 10 PROCEDURE // GENERAL RECOMMENDATIONS WARNING Avoid using sharp objects Always ensure the proper with the product. power input. Before you plug in the equipment be sure that the electric supply of your country or region is the right one to operate the equipment.
- Page 11 PROCEDURE General recommendations Initial settings Operating...
- Page 12 PROCEDURE Place the LCD control away from the // GENERAL RECOMMENDATIONS Locate the test subject at an subject to prevent him/her to see the appropriate distance informa�on displayed. f . rom the equipment body Be sure the support points are in contact with the suppor�ng surface.
- Page 13 PROCEDURE WHAT SHOULD // INITIAL SETTINGS BE INCLUDED IN THE PACKAGE? Depending on the geographical area, you will be given one of these AC cables (one per package). a. Depth Perception Apparatus body X1 // b. Joy Stick Control x 1 // c. LCD control x 1 // d. DIN 5 cable x 1 e.
- Page 14 PROCEDURE HOW TO ASSEMBLE IT? // INITIAL SETTINGS USB CABLE USE ONLY IF CONTROL SOFTWARE IS AVAILABLE POWER CABLE. The smallest end B of the USB cable (f) should be connected to this port. The opposite end of cable A should be Connect the A/C cable The opposite end should be connected to a 110/220VAC- 50/60Hz power outlet.
- Page 15 1” CABLE CONNECTION AC POWER CABLE SET UP Connect the AC power cable (g) MAIN LCD CONTROL Connect the main LCD control to the main unit using the corresponding (e) DB25 to USB 3.0 cable connector. ATTENTION! Please verify that the neither (f) USB B connector is connected to the equipment or the USB A connector is connected to the PC when you start the equipment.
- Page 16 TURNING ON TURN ON Before turning the equipment On. Please verify that all the cables are connected correctly. Please, double check that the AC power cable is safely and securely plugged to both the main unit and the AC wall outlet. Also, check that all the cables are set accordingly to the previous steps.
-
Page 17: What Does It Mean
PROCEDURE WHAT DOES IT MEAN? // INITIAL SETTINGS DIS: S means STATUS and makes reference to the TEST STATUS. DIS means distance. Distance can be either posi�ve or nega�ve from the beginning point, indica�ng direc�on. Distance is given in tenths of millimeters (1/10). TIME: TS means TEST and makes reference to the of the test number currently running . - Page 18 SLECTING TEST PROCEDURE Starting a test. Ending a test. // OPERATING A total of 10 tests ( trials) can be selected using the “UP” and “DOWN” keys. Stop DIS : 0 S : SAve DIS : 0 S : STP TIME : 0 TS : 2 TIME : 0 TS : 2 Selected test will be stopped and...
- Page 19 PROCEDURE USING THE SLIDER’S PUSHBUTTON // INITIAL SETTINGS Push Button Actions. Push button will cause some actions when pressed or depressed in a given state “S” as follows: IF Start/Stop Bu�on is AND Push sliding sensor in THEN IF Start/Stop Bu�on is AND Push sliding sensor in THEN Start...
- Page 20 Push Button Actions IF Start/Stop Bu�on is AND Push sliding sensor in THEN Start Note DIS : 1587 S : STR TIME : 22065 TS : 2 At this point you have been followed the connection and execution steps without the software; If you want to implement the device with this, you can go to: Start Button was pressed once at...
- Page 21 Running the Controlling Software USB Cable While the computer is on and OS is running, Connect the USB B connector of the provided execute the Controlling software by double-clicking USB Cable to the main unit, then connect the on its icon. Follow up the instructions presented USB A connector to a computer's USB port.
- Page 22 (+57 1) 6275686 (+57) 3003642343 Cll 147 A # 48 - 08. Bogotá, Colombia 2550NW 72nd Ave. Suite 115. Miami, Fl. 33122. De la Rosa Research Team. support@delarosaresearch.com (+57 1) 6275686 (+57) 3003642343 Cll 147 A # 48 - 08. Bogotá, Colombia...
