Technical Features of the S4e UtiliNet

S4e and UtiliNet Specifications
Applicable Standards
ANSI C12.1-2001
ANSI C12.10-1987
ANSI C12.20-1998
CAN3-C17-M84
CAN3-Z234.4-79
FCC
Industry Canada
NOM
Application Information
Frequency
Nominal Voltage
Operating Voltage
Operating Temperature
Meter
UtiliNet Radio
Humidity
Meter
Rated Accuracy at Unity Power Factor
Transformer-Rated/
Self Contained Meters
K-Base Meters
Over voltage Withstand
Temporary (.5 sec)
Continuous (5 hours)
Starting Load:
Class 20
Class 200
Class 320
Available Meter Forms
Base Transformer Rated
Class 20
S-Base 3, 9/8, 45(5)*,
36(6)*, 29, 56
A-Base 10/8, 45(5)*, 36(6)*
K-Base
*36S/36A replaces the traditional 6S/6A, 45S/45A replaces the traditional 5S/5A
**Class 320 Meters are referred to as SE base
Bulletin Number: 20031201 Rev A
for electricity metering
for watt-hour meters
for solid-state electricity meters
Canadian Specs for approval of electrical meters
Canadian Specs for all-numeric dates and times
Certified Part 15.247
RSS 210
121-SCTI-1994
50 or 60 Hz +/- 5%
120-480 VAC ranging
80-115% of nominal
-40 to +85 C under cover
-40 to +60 C under cover
Meter Less than or equal to 95% relative humidity, non-condensing
0
UtiliNet rated 65 C at 90% relative humidity, non-condensing
+/- 0.2%
+/- 0.5%
150% rated voltage
120% rated voltage
0.004 amps
0.050 amps
0.050 amps
Class 120
16/15/14
S4e-UtiliNet User Manual
Class 200 Class 320**
2, 12, 25, 2, 12, 16/15/14
16/15/14
Class 480
12, 16/15/14,
and 27
