DAKOTA DIGITAL
• Each unit is completely individual, no control box
• Exclusive warning feature allows reading to flash when outside normal operating limits
• Start up circuitry provides fast accurate readings and no waiting for readings to stabilize
• All units feature high contrast, non-glare teal displays for excellent daytime visibility
and have nighttime dimming capability
• 2-year manufacturer's warranty
6000 SERIES
21-1044
6000 SERIES DIGITAL SPEEDOMETER/TACHOMETER
• Measures 4-1/2" long, 1-5/8" tall and 1-1/2" deep
• 30% smaller than the 5000 series speedo/tach
• Uses new high brightness vacuum fluorescent graphic display technology
• Contains all indicators including turn signal, high beam, neutral, low oil
pressure and engine for fuel injected models
• Odometer, tripmeter and user selectable bar/graph tachometer range of
0-5000, 0-8000 and 0-16,000 rpms also included
• Menu driven setup allows easy configuration and calibration
• Mfg/N HLY-6000
21-1044
$645.00
2000 SERIES
2000 SERIES DIGITAL GAUGE
5" DIGITAL TANK MOUNT SPEEDO
• Installs into stock instrument cluster and uses standard speedo cable or reads stock
H-D electronic sensor
• Speedo reading to 255 mph
• Bar graph tachometer
• Resettable trip odometer
• Turn signals and high beam indicator
• Low voltage and oil warning indicators
• Neutral indicator
• 1 button speedometer calibration
• Road Kings may require harness modifications
• Will not fit EFI 00-01 Softail or Road King
21-1000 Fat Bob Style Tanks (Mfg/N HLY-2000)
INSTRUCTIONS
DAKOTA DIGITAL
21-1000
$445.00
BIKER'S CHOICE
NEW PART NUMBERS ARE RED
49-8608
MOUNTING BRACKETS FOR 6000 SERIES GAUGE
P/N
Description
1-1/2" Bar Mount Bracket (Mfg/N BKT-5005)
49-8608
49-8609
1" Riser Mount Bracket (Mfg/N BKT-5006)
49-8610
1-1/4" Riser Mount Bracket (Mfg/N BKT-5007)
1-1/2" Riser Mount Bracket (Mfg/N BKT-5008)
49-8611
Sportster Mount (Mfg/N BKT-6010)
49-8619
49-8624
Deuce Mount (Mfg/N BKT-5011)
49-8627
Steel Housing (Mfg/N BKT-6012)
21-1001
P/N
Application
Pick-Up Adapter for 2000 Series
• Speed adapter is required
21-1001 96-04 H-D Models (Mfg/N SEN-2012)
Sender Unit for 2000 Series
• 5/8" - 18
21-1002 For Front Wheel Speedo Drives (Mfg/N SEN-2011)
Road King Harness
21-1025 Carbureted Models
INSTRUMENT & LIGHTING
49-8609
49-8627
Retail
$80.00
89.00
94.00
99.00
99.00
89.00
99.00
21-1002
Retail
$19.95
$34.95
$19.95
