- Page 1 WALKTHROUGH METAL DETECTOR Body Temperature Measurement 2MTHWT-HMD Quick Guide Manual Version: V6.1 REV06122020...
-
Page 3: Installation Precaution
Body Temperature Measurement – Quick Guide V 6.1 Disclaimer The infrared temperature measuring device is the human body surface temperature screening instrument. The test results only reflect the real-time temperature evaluation of objects or people in a specific environment. The selling company and the manufacturer shall not bear any responsibility for the direct or indirect loss caused by the use of the test results. -
Page 4: Temperature Sensor Connection
Body Temperature Measurement – Quick Guide V 6.1 Interface Alarm count of over temperature and metal detected, Shifted by button Power Body temperature and Metal safety pass count Shifted by button Power Power Select Adjust Confirm Temperature sensor Connection Connect the wires with the right colors one by one. Wrong connection may damage the temperature measurement module. - Page 5 Body Temperature Measurement – Quick Guide V 6.1 Commission instruction Step 1, press D button to enter below: Password input Power Select Adjust Confirm Step 2, press B to shift and C to adjust to enter the password 1318, press D button to enter below: Temperature compensation settings Alarm temperature setting...
-
Page 6: Restore Factory Settings
Body Temperature Measurement – Quick Guide V 6.1 Temperature unit switching Press B button in the main interface, it shows F or C. F represents Fahrenheit, C represents Celsius. Press A button for 3 seconds to adjusting interface. Press A button twice to main interface. Press B and A to adjust if necessary. -
Page 7: Language Settings
Body Temperature Measurement – Quick Guide V 6.1 Language settings Press D button in the main interface (display CCCC), press B button to enter the password input interface (display 1234), and press B button and C button to input the password 1323. Press D button to display FFFF, indicating the password is correct. - Page 8 Body Temperature Measurement – Quick Guide V 6.1 ● L001-L006 of the first line is the metal detection zone from bottom to top, 975 (or other values) of the second in represents the metal detection sensitivity, high sensitivity for tiny metals. ●...
-
Page 9: Common Troubleshooting
Body Temperature Measurement – Quick Guide V 6.1 7. Measurement time: 0.5 seconds. After the measurement, please leave quickly. Otherwise the measurement will be repeated. 8. During the temperature measurement, influenced by the measurement speed, the temperature might suddenly fluctuate up and down. In this case, please measure the body temperature 3-5 times continuously, and take the average value as the final measurement result. - Page 10 Body Temperature Measurement – Quick Guide V 6.1 Infrared Temperature Sensor Schematic diagram of temperature measurement...
- Page 12 802 Greenview Dr. Suite 200, Grand Prairie TX. 75050 USA Toll Free: (866) 708-5401 Fax: 214 988-2858 support@2mtechnology.net...
