- Page 1 WALKTHROUGH METAL DETECTOR 6 Zones w/Single Wrist Thermal Sensor 2MTHWT-HMD User Manual Manual Version: V2.0 REV06122020...
-
Page 2: Table Of Contents
Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD CONTENTS Precautions ..................3 Suitable places .................5 Performance and characteristics ............5 Installation conditions ...............6 Installation specification ..............7 Display specification .................8 Operating specification ..............9 Detection adjustment ..............14 Common problem handling .............15 Standard compliance ..............16 Technical parameter ...............17... -
Page 3: Precautions
2M Technolgy User Manual PRECAUTIONS The Walk-through Metal Detector (WTMD) is only available for indoor use. Outdoor installation is not allowed, otherwise rainproof / sunproof facilities such as awnings shall be used. II. The Walk-through Metal Detector (WTMD) shall not be installed at high temperature and mois- ture places. - Page 4 Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD PRODUCT INTRODUCTION 1. Main case 2. Top cover 3. Plastic strip 4. Door plate 5. Led light bar 6. Infrared sensor 7. Stabilizer Bas 8. Power supply socket Stabilizer Base Power supply socket Cable Walk-through Metal Detector is a kind of fixed installed detection equipment.
-
Page 5: Suitable Places
2M Technolgy User Manual SUITABLE PLACES Suitable for law enforcement agencies: Including public security departments, procuratorates, courts, prisons, reforma- tories and penitentiaries etc. requiring forbidden metallic article inspection. II. Suitable for public places: Including public places such as gymnasiums /stadiums, recreation places, airports, customs authorities, exhibition halls and museums etc. -
Page 6: Installation Conditions
Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD INSTALLATION CONDITIONS Stationary metal articles The Walk-through Metal Detector (WTMD) shall be at least 50cm away from stationary or fixed big metal articles, otherwise false alarms will be caused. II. Movable metal articles... -
Page 7: Installation Specification
2M Technolgy User Manual INSTALLATION SPECIFICATION Installation instruction 1. Remove the packages of the main case and door plates. 2. Face the panel of the main case down, put the right and left door plates (as shown in the figure) at the specified places and put the fitting box aside. -
Page 8: Display Specification
Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD DISPLAY SPECIFICATION I. Panel specification 1. The left side of the panel is zone panel. The big green light at the top is the power indicator light, and the big red light next to it is the alarm indicator light. The small red lights below the power indicator light are used for loca tion indicating. -
Page 9: Operating Specification
2M Technolgy User Manual OPERATING SPECIFICATION KEY SPECIFICATION: 1. The “RES” has two functions for the actual operation: (1) On / Off: The system can be started up by pressing it for more than ls and shut down by pressing it for more than 3s. - Page 10 Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD 4. Check of program version number: As shown in Fig. 2, the program version number will be shown on the screen when “SEL” is pressed twice continuously at the main interface. The main interface will be recovered when “SEL” is pressed again.
- Page 11 2M Technolgy User Manual Fig. 2 III. FUNCTIONAL PARAMETER SETTING The parameters of the Walk-through Metal Detector (WTMD) can be set according to the requirement. The parameter set- ting is password protected and therefore the parameter setting menu can only be shown after the password is input correctly. Figure 6~13 shows the input password.
- Page 12 Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD 1. Password modification (1) Input the correct password or “1111” and press “ENT” to show Fig. 14, then press “SEL” to enter the password modification menu, see Fig. 26. (2) Press “SEL” to select password digits. The digit can be changed by pressing “ADJ” until the 4-digit password is set, see Fig.
- Page 13 2M Technolgy User Manual Ringer volume set and press “SEL” is shown in Fig. 25 (or Fig. 46), enter the alarm time settings, 0.5S ~ 4.0S adjustable alarm time, press “ADJ” to change the time, in increments of 0.5S, It will return 0.5S after more than 4s. 4.
-
Page 14: Detection Adjustment
Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD pends on surrounding environment, if there is only small interference, then filtering can be omitted. When more (more than 4) Walk-through Metal Detector (WTMD)s are working at the same time, there will be certain interference, thus caus- ing false alarm, so filtering mode is necessary. -
Page 15: Common Problem Handling
2M Technolgy User Manual as well as impacting the door plate are not allowed. 4. For the WTMD inspection, the person shall be inspected after the last one passes the warning line without triggering the alarm. If an alarm is triggered, the person shall be inspected after the alarm tone stops. 5. -
Page 16: Standard Compliance
Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD 2. If the alarm failure still exists though the oscillation signal is normal, the DC power values of the motherboard shall be checked for being +8V, -8V and +12V respectively with a multimeter. -
Page 17: Technical Parameter
2M Technolgy User Manual TECHNICAL PARAMETER OPS: AC 100V ~ 240V 50 / 60Hz Actual power consumption: < 12W Signal freq.: 7000Hz ~ 8999Hz, adjustable Operating ambient temperature: -20 ~ 45°C Operating ambient humidity: :S 98% Weight of entire packaged product: Approx: 70kg Overall dimension: H 2220MM x W 830MM x D 500MM Passage size: H 2000MM x W 710MM x D 500MM Package size: Door plate: L 2300MM x W 640MM x H 240MM... - Page 18 Walkthrough Metal Detector with Single Wrist Thermal Sensor 2MTHWT-HMD INSPECTION REPORT PACKING LIST www.2MTechnology.net...
-
Page 19: Green Channel" After-Sales Service System
2M Technolgy User Manual “GREEN CHANNEL” AFTER-SALES SERVICE SYSTEM Instant response: 24h hotline support; Reply within 4h; Service providing within 24 - 48h. II. One-month guarantee for replacement: Any product with quality problem confirmed by the quality inspection department of our company can be replaced within 1 month after the purchase date. III. - Page 20 802 Greenview Dr. Grand Prairie TX. 75050 USA Toll Free: 1-866-708-5401 Fax: (+1) 972-999-4113 sales@2MTechnology.net...
