- Page 1 EBS-50 Smart Base station ESL base station with built-in server Specifications manual...
- Page 2 Opticon assumes no liability for any direct, indirect, consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon has been informed about the possibility of such damages.
- Page 3 Revision History EBS-50 Specifications Manual Edition Date Page Section Description of Changes October 21, 2020 Initial release.
-
Page 4: Table Of Contents
Contents Overview ..........................6 About the EBS-50 Smart base station ................7 Physical Features ....................... 8 Weight ........................8 Dimensions ......................... 8 Maximum total height ....................8 Mounting ........................9 Environmental Specifications ....................10 Operating Temperature and Humidity ................10 Storage Temperature and Humidity ................10 Static Electricity ......................10... - Page 5 Figure 1: EBS-50 Dimensions ........................8 Figure 2: EBS-50 Maximum height ....................... 8 Figure 3: Mounting plate ..........................9 Figure 4: Attaching and detaching the EBS-50 to the mounting plate ............9 Figure 5: Drop test ............................10 Figure 6: Interfaces ............................. 12 Figure 7: Wi-Fi Dongle ..........................
-
Page 6: Overview
50 can then be done from any location provided that that location is connected to the same network as the EBS-50. It is even possible to do that from a remote location but in that case, a VPN tunnel is required because of safety concerns. The EBS-50 can setup that VPN tunnel by itself, provided that the remote location already has a VPN server running but this is usually not needed. -
Page 7: About The Ebs-50 Smart Base Station
USB-OTG port, with a micro USB style connector. The main use of the host port is for a Wi-Fi dongle and Opticon will come with a list of approved dongles for which the driver is already installed. This port however can also be used for software updates that come on a USB-stick for those situations where the EBS-50 cannot connect to the Internet. -
Page 8: Physical Features
3.1 Weight The weight of the EBS-50 is approx. 250g (TBD) 3.2 Dimensions The dimensions of the EBS-50 base station: 145 x 110 x 27.1 mm (179.6x158.3x27.1 mm with the antennas mounted alongside the main housing). Figure 1: EBS-50 Dimensions 3.3 Maximum total height... -
Page 9: Mounting
The EBS-50 comes with a mounting plate for easy mounting to e.g. a wall or the ceiling. The EBS-50 can slide over the mounting plate to click and lock it into place. To unlock it, use a flat screwdriver to push the locking tap down and then slide the EBS-50 away from the screwdriver. -
Page 10: Environmental Specifications
± 8 kV (No damage but operator involvement may be required) 4.4 Drop resistance. The EBS-50 has withstood the following drop test: Drop the base station 12 times (3 times at each of 4 orientations), from a height of 1m onto a concrete floor as shown below. -
Page 11: Electrical Specifications
Radio Baud rate 250 Kbits / second Number of independent radios Channels 1~10 are reserved for sub-GHz frequencies, which are not supported by the EBS-50. Local regulations may not allow the use of these channels. Parameter Unit Remarks Receiver sensitivity -100.3... -
Page 12: Interfaces
6 Interfaces The drawing below shows the position of the various interfaces on the EBS-50 Figure 6: Interfaces Item Interface Connector type Description USB-Host Female USB type A For USB gadgets such as a Wi-Fi dongle Reset switch USB-OTG Female USB micro... -
Page 13: Reset Switch
6.2 Reset switch The reset switch can be used to reset the EBS-50 to factory default. This can be used for instance when the operator has made a mistake and has accidentally locked the EBS-50 out from the network. Since the EBS-50 must be controlled via a web-browser, a working Ethernet connection is required to change the setup, so when that is not working the reset switch is the only thing that can bring the EBS-50 back online. -
Page 14: Indicators
7 Indicators The EBS-50 has 5 LED indicators that are visible from the top of the device. Figure 9: LED Indicators Power. This LED turns red right after the power is applied. The internal computer will then start running and when it is done with the boot process, the led will turn green. If the LED stays red for several minutes, a severe problem has occurred. -
Page 15: Labels
802.15.4 MAC address: M1M2M3-SaSbS1S2S3 M1M2M3 defines the manufacturer ID, which is 00126A for Opticon and is the same for both address types. The bytes that follow the manufacturer ID, define the product number which is three bytes long for an Ethernet address and 5 bytes for an 802.15.4 address. To convert the two, we have set SaSb both to zero. -
Page 16: Label Positions
1 4 8 2 8 Figure 13: White box label The white box label lists the item number and serial number just as on the product label. It also shows a GTIN barcode that has the Opticon manufacturer number and the article code encoded. -
Page 17: Shipment Box Label
The shipment box label is Opticon’s standard shipment box label and contains information about the order number, box quantity, manufacturing spec. number, software versions etc. The label also contains a GTIN barcode. The label is according to Opticon’s shipment box standard rev 9 and the size is 160x105mm. -
Page 18: Packing
9 Packing 9.1 Individual packing After putting the base station in a foam bag, it is packed in a white box with the following accessories: Two antennas One quick start guide The safety instructions One mounting plate The white box size is 19x5.5x15.5cm. Figure 15: Individual packing... -
Page 19: Shipment Packing
9.2 Shipment packing 30 individual EBS-50 boxes are packed into one shipment box. The weight of the shipment box is 10kg TBD Figure 16: Shipment packing... -
Page 20: Software Configuration
10.1 Basic setup To start working with the EBS-50, the first step that needs to be done is to connect it to a network via Ethernet. Once that is done, the EBS-50 can be configured via any computer on the same network. - Page 21 This is the ESL dashboard that shows an overview of the system, such as the status of the ESL’s, the database, the server etc. This is all explained in the user manual of the EBS-50. The most important step is to configure the network here which is why this part is added to this specification manual.
- Page 22 Time settings Factory Default Reboot When Wifi Server is set to ‘On’, System Settings the EBS-50 will behave like a Wifi Network Settings ▼ access point allowing clients to Ethernet connect to it. The Wifi client menu is then disabled.
- Page 23 Reboot System Settings The IP settings under the Wifi Network Settings ▼ Server option, allows you to select the EBS-50’s own IP address (the Ethernet default gateway) and subnet OpenVPN mask. It also allows you to enable a DHCP server that can configure ▼...
-
Page 24: Esl Server Setup
10.2 ESL Server setup The ESL server setup is described in an external manual TBD TBD...
