Sunset Trading OPTIONS-52PHR Assembly Instructions

A
B
1、Slide the metal receiver over the
metal post.Press both sides of back
firmly downward until locked in place.
Note: Make sure all
PLUGS are connected on
the product before
plugging power cord
into power outlet. If
not damage can occur.

Assembly Instructions for OPTIONS-52PHR

C
A
B
D
E
F
5、Apply The Wings
Insert the male KD Bracket into the slot of
the female Bracket pressing firmly
downward until the frame is tight.
E
F
G
3、Locate the light cord E
attached to the bottom back
and connect to plug F
located at the rear of seat.
Male
2、Locate the power cord C
attached to the bottom back and
connect to plug D located at the
rear of seat.
C
D
C
D
P P
4、Locate the transfomer P and
connect to DC Port located at the rear
of arm.
Female
