RIKA SYMBIA Operating Manual
Hide thumbs Also See for SYMBIA:

Advertisement

Quick Links

SYMBIA
Operating manual

Advertisement

Table of Contents
loading

Summary of Contents for RIKA SYMBIA

  • Page 1 SYMBIA Operating manual...
  • Page 2: Table Of Contents

    Suitable fuels and fuel amounts ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 Wood types �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 Output controlling ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 Clean combustion ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 7. MANUAL OPERATION RIKA firelighter ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������21 Combustion air regulation ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������21 Correct heating up ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 Nachlegen �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 8. CLEANING AND MAINTENANCE Basic information ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 23 Cleaning the combustion chamber ��������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 3: Explanations To Symbols

    10. GUARANTEE CONDITIONS 11. WARRANTY CONDITIONS 12. DISPOSAL INFORMATION Information on the individual components of the device ���������������������������������������������������������������������������������������������������������������28 Extract from the waste code of the European Waste List Regulation ���������������������������������������������������������������������������������28 Electronic Waste ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������28 1. EXPLANATIONS TO SYMBOLS ...Important ...Useful ...Manually ...Fragile Note...
  • Page 4: Technical Documentation - Ecodesign

    TECHNICAL DOCUMENTATION 2. TECHNICAL DOCUMENTATION - ECODESIGN according to commission regulation (EU) 2015/1185 und 2015/1186 Ecodesign Contact details of the manufacturer Manufacturer: RIKA Innovative Ofentechnik GmbH Andreas Bloderer Contact: Address: Müllerviertel 20 4563 Micheldorf Austria Details of the device Model Identifier:...
  • Page 5 Micheldorf, 07.12.2021 In case of doubt as well as missing or incorrect translations, the German version is the only valid one.  Subject to technical and visual changes as well as layout and printing errors. © 2021 | RIKA Innovative Ofentechnik GmbH...
  • Page 6: Technical Data

    3. TECHNICAL DATA Spare part overview exploded diagram...
  • Page 8: Stone Casing

    Stone casing...
  • Page 9 Stone casing...
  • Page 10 Stone casing...
  • Page 11: Steelshell

    Steelshell...
  • Page 12 Steelshell...
  • Page 13 Steelshell...
  • Page 14: Spare Part Overview Article Numbers

    Spare part overview article numbers Nr. Art.Nr. Description Nr. Art.Nr. Description Z38268 Door frame B18750 Telescopic rail right N112655 Hollow seal D06 Z37954 Firebrick lining bottom front Z37663 Decorative glass Z37955 Firebrick lining bottom left N112658 Sealing cord D08 Z37961 Firebrick lining left N112169 Hexagon socket screw...
  • Page 15 Nr. Art.Nr. Description Nr. Art.Nr. Description Z37742 Side panel white stone, top LB00749 Top steel front Z37800 Side panel concrete, top B18767 Cover right B18767 Cover right LB00907 Bottom steel front Z37735 Side panel soap stone, bottom right L03715 Mount left Z37736 Side panel white stone, bottom right B18577...
  • Page 16: Dimensions

    Dimensions Technical data Technical data Heating power range [kW] 4 - 8 Room heating capacity (depending on 90 - 210 house insulation) Fuel consumption [kg/h] ~2,2 Efficiency >80% testing CO-emission on 13% O [mg/m <1250 Dust emission [mg/m <40 Exhaust [g/s] testing Exhaust temperature...
  • Page 17: Important Information

    RIKA stoves should only be installed in rooms with normal humidity (dry areas according to VDE 0100 Part 200)� The furnaces are not splash water protected and may not be installed in wet areas�...
  • Page 18: Prior To Set Up

    Stoves type 1 (BA 1): Prior to set up Suitable for multiple occupancy� (Note the different country Floor bearing capacity regulations�) Ensure that the substructure is capable of bearing the weight of the These may only be operated with the combustion chamber door stove prior to set-up�...
  • Page 19: Installing The Stove

    Connect at the air intake either a pipe Ø 125 mm for log wood and We recommend original flue pipes from RIKA for proper connection� combi stoves, or Ø 50 mm or Ø 60 mm for pellet stoves� Fix it with a hose clamp (not included!)�...
  • Page 20: Brief Information On Combustible - Logs

    6. BRIEF INFORMATION ON COMBUSTIBLE - LOGS Suitable fuels and fuel amounts Output controlling Your stove is generally suitable for burning dry firewood� You can The output of your stove is regulated manually or via the Rikatronic- also burn combustibles such as wood briquettes� control�...
  • Page 21: Manual Operation

    RIKA firelighter Always ignite the RIKA firelighter on the red tip� One block consists out of 8 ribs which can be divided to the desired size� The amount of RIKA firelighters also depends on the size and humidity of your firewood�...
  • Page 22: Correct Heating

    3� Now place further pieces of chipboard in crosswise layers on top explosive gas/air mixture may arise and cause an eventual heavy of the logs and place 2-4 ribs of the RIKA-firelighter on the left on top deflagration� For safety reasons it is recommended to leave the of the chipboard�...
  • Page 23: Cleaning And Maintenance

    8. CLEANING AND MAINTENANCE Basic information Empty the ash drawer Empty the ash drawer regularly� The ash drawer is simply lifted out Note with the combustion chamber door open� When you vacuum clean around the stove ensure that you do not vacuum into the combustion air intake during heating operation�...
  • Page 24: Cleaning The Flue Gas Outlet

    Cleaning the flue gas outlet (annually!) Remove the flue pipes� Inspect and clean the chimney connection� Brush off any soot and dust deposits in the fire and in the flue pipes and vacuum�...
  • Page 25: Checking Seals

    Checking seals (annually) Check the condition of the seals at least once a year� Repair or replace seals depending on condition� Note Only intact seals ensure your stove works perfectly! You will find the seals in the spare part overview� Note Accumulated fly ash in the flue gas channels may impair the performance of the stove and pose a safety risk�...
  • Page 26: Problems - Possible Solutions

    9. PROBLEMS - POSSIBLE SOLUTIONS Problem 1 Problem 2 Fire burns with weak, orange flame, window is sooted up� Stove smells strongly and / or fumes are emitted� Cause(s) Cause(s) Poor chimney draught Burning-in phase (taking into service) Damp wood Stove has accumulated dust and/or dirt Possible solution(s) Incorrect heating up...
  • Page 27 In cases of doubt, or in the case of missing or incorrect translations, the German version is always the sole valid version. In the interest of ensuring damage limitation in good time, the guarantee claim should be sent in writing to the RIKA specialist or contract dealer.
  • Page 28 12. DISPOSAL INFORMATION RIKA Innovative Ofentechnik GmbH is ensuring that its products Extract from the waste code of the are eco-friendly throughout the product life cycle� This is why our European Waste List Regulation commitment for electronic products goes beyond the end of their product life cycle�...
  • Page 32 German version is the only Müllerviertel 20 valid one. Subject to technical and visual 4563 Micheldorf / AUSTRIA changes as well as layout and printing errors.. Tel.: +43 (0)7582/686 - 41, Fax: -43 © 2021 | RIKA Innovative Ofentechnik GmbH verkauf@rika.at www.rika.at...
