Sealey PC40.V2 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
WARNING! The blade used by this cutter is razor sharp and should be treated with due
‰
caution.
Store the cutter in a safe childproof place when not in use.
9
Use in a suitable, clean and tidy work area, free from unrelated materials. Ensure there is
9
adequate lighting.
Use the cutter for rubber and soft vinyl pipes only.
9
DO NOT use cutter on hard reinforced pipe. If the blade does not penetrate the pipe, then the material used to make the pipe is too hard.
8
Applying excessive pressure may cause the pipe to shatter.
DO NOT continue to attempt cutting any pipe that withstands penetration.
8
DO NOT insert a finger into the cutting area at any time.
8
DO NOT turn the pipe whilst cutting.
8
DO NOT allow untrained people to use the cutter.
8
DO NOT allow children to use or play with the cutter.
8
DO NOT use the cutter for tasks it is not designed to perform.
8
DO NOT operate cutter if any parts are damaged or missing as this may cause failure and/or personal injury.
8
DO NOT operate the cutter when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
2. INTRODUCTION
Pistol-type, ratchet action, die-cast aluminium alloy body with heat treated AUS-8 stainless steel blade honed and shaped for smooth cutting action.
Ratchet cutting action avoids crushing pipe. Long-life blade suitable for cutting extrusions and pipes. Textured grip with rubber inlay gives added
comfort and control.
3. SPECIFICATION
Model: .....................................................................PC40.V2
Capacity: ................................................................ Ø6-42mm
Length: ....................................................................... 210mm
4. OPERATION
PLACE PLASTIC PIPE INTO
'U' JAW WITH THE BLADE
POINT ALIGNED WITH THE
TUBE CENTRE
© Jack Sealey Limited
PLASTIC PIPE AND EXTRUSION CUTTER
PC40.V2
MODEL No:
SQUEEZE TRIGGER HANDLE
REPEATEDLY TO PIERCE AND
CUT THROUGH THE PIPE
Original Language Version
PART NUMBER FOR SPARE BLADE
PC40/B
TO RETRACT THE BLADE
PUSH THE BUTTON AT THE
REAR OF THE TOOL
PC40.V2 Issue 3 12/10/21
