  • Page 1 Quick Reference Guide...

  • Page 2: Safety Notes

    QUICK REFERENCE GUIDE About This Guide The VIP Drive 10-5 Nova Quick Reference Guide (QRG) has basic product information such as connection and menu options. Download the User Manual from www.chauvetvideo.com for more details. Disclaimer The information and specifications contained in this QRG are subject to change without notice.
  • Page 3 Mounting The VIP Drive 10-5 Nova fits on a standard 19-inch rack, or it can be placed on its rubber feet on a flat level surface. Product Front Overview...

  • Page 4: Product Rear Overview

    DVI (HDMI 1.4) 2 inputs. OPT 1-1 SFP ports (master and backup) for sending/receiving fiber optic data at distance via SFP modules OPT 1-2 HDMI 1.3 HDMI 1.3 video output port for monitor VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 5 QUICK REFERENCE GUIDE Menu Map Refer to the VIP Drive 10-5 Nova product page on www.chauvetvideo.com for the latest menu map. Main Level Programming Levels Description Screen 0–100% Controls total output level Brightness Sets number of rows in video Cabinet Row 1–64*...
  • Page 6 Layer Settings PIP1 OPT1-1 PIP2 OPT1-2 MOSAIC Scales the layer to the entire Full Screen connected video assembly Scaling Mode Pixel to Pixel Scales the layer 1:1 Custom Scales the layer manually VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 7 2560 x 1080 Available frame rates (Hz): 50, 59.94, 2560 x 1600 Available frame rates (Hz): 50, 59.94, Available frame rates (Hz): 30, 50, 3840 x 1080 59.94, 60 3840 x 2160 Available frame rates (Hz): 30 VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 8 Adjusts the input hue Reset Resets the input color settings Displays color space and sample rate Color/Sample RGB 4:4:4 of the input source Activates/deactivates color range Limited to Full conversion from RGB Limited to RGB Full VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 9 Sets the horizontal offset of this Load Area Initial X 0–32668 product’s output Sets the vertical offset of this product’s Load Area Initial Y 0–32668 output Resets the image mosaic settings to Reset factory default VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 10 Selects backup input source for each Settings input connector Input Backup DVI1 ↔ DVI2 Backs up mosaic HDMI source with a MOSAIC(H) ↔ mosaic DVI source MOSAIC(D) Resets the input backup settings to Reset factory default VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 11 25, 29.97, 30, 48, 50, 59.94, 60 HDMI Output Available frame rates (Hz): 50, 59.94, 1920 x 1200 23.98 29.97 Frame Rate Monitor frame rate. Availability based (Hz) on selected resolution. 59.94 Applies the selected HDMI output Apply settings VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 12 More Settings Disables third-party emitter Third-Party Emitter Enables third-party emitter Enables use of OPT 2 port as backup Backup output port OPT 2 Mode Copies the data flow of the connected Copy fiber converter VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 13 _ _ _ _ _ _ _ _ H_VERSION H_TEMP_BD _ _._ (C) H_VCC_BD _ _._(V) H_TEST_COUNT S0_TEMP _ _._ _(C) S1_TEMP _ _._ _(C) About Firmware Version _ _._._ _._ _ Displays the current firmware version VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 14 Sets the device to process fiber optic Working Mode Fiber Converter video input to Ethernet output Deactivates video processing ByPass functions English Sets display language to English Language 中文 Sets display language to Chinese VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 15 QUICK REFERENCE GUIDE THIS PAGE INTENTIONALLY LEFT BLANK VIP Drive 10-5 Nova QRG Rev. 2...
  • Page 16 Voice: +52 (728) 690-2010 Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Mexico, France, Germany, or Benelux, contact the dealer of record. VIP Drive 10-5 Nova QRG Rev. 2...
