Quick Start Guide
Page 1 of 2
Mount Extraction Finder Adapter
securely.
Install a bypass, valved bleedport.
©2021 Arometrix Inc. • Phone: 240-492-6556 • sales@arometrix.com • arometrix.com
On the bottom-end of Extraction
Adapter, connect a 1.5" Sanitary
Flange to Hose Adapter (or NPT or
another connection) for incoming flow.
Best Practice: Set up an extraction
adapter bypass (that can be quickly
actuated through 3 way valves), a
vent, and a pressure gauge.
LEAK TEST FITTINGS TO ENSURE INTEGRITY
General Process
Flow for
Hydrocarbon
Extraction
On the top-end of the Extraction
Adapter, connect a second 1.5"
Sanitary Flange to Hose Adapter (or
equivalent) for outgoing flow.
Warning: Ensure all connections are
properly installed. Ensure the system
and installation conform to all
applicable laws and ordinances.
