ACCESS CHAIR 18" / ACCESS CHAIR 21" / ACCESS CHAIR 24"
300 LB. [136 kg] / 350 LB. [158 kg] / 400 LB. [181 kg]
MANDATORY
LEAVE THIS MANUAL WITH OWNER
Read and follow all instructions.
Safety can only be ensured if the Pool
Access Chair is installed and operated
according to these instructions.
FOR SAFETY REASONS
• NEVER
swim alone
• NEVER
permit children to play on or around the chair
• DO NOT
allow children to use the chair without adult
supervision
READ CAREFULLY
Check entire box and all packing
materials for parts. Before beginning
assembly, read the instructions and
identify parts using the figures and
parts listed in this document.
It is critical that all parts be carefully
inspected prior to installation. If any
damage occurred in transit, Aqua Creek
Products, LLC must be notified within
three days of receipt of unit.
Proper installation cannot be
overstressed, as an improper
installation voids Aqua Creek's warranty
and may affect the safety of the user.
POOL ACCESS CHAIR
USE THIS MANUAL FOR PART #'s:
F-520SPM / F-520WSPM / F-520XWSPM
1
