- Page 1 PU843,030-040 Check out easy mounting of your kitchen L03841, (355-359) L03831, (355-359) Drawer front Drawer front 30 cm 40 cm L03841, (355-359) L03831, (355-359) Drawer front Drawer front 40 cm 30 cm 02-09-2018 0b...
- Page 2 PU843,030-040 Check out easy mounting of your kitchen DU80,***,000 / 176 (Support ) (Suspension list) (Side) (Back panel) (Base-top) 1 pcs 1 pcs 1 pcs 1 pcs 2 pcs BP21X14 / BP21X13 Drawer slide Left Drawer slide Right Alu profil 040 / 030 ID20102 ID20103 2 pcs...
- Page 3 PU843,030-040 FIG. Side Left Screw flh Euro screw 3,5x15 mm 6,3x11 mm 4 pcs 2 pcs (Side) Screw flh 3,5x15 mm Screw flh Screw flh 3,5x15 mm 3,5x15 mm 1 pcs 3 pcs Rail holder 30,5x30,5 m/ 8 1 pcs NB!!! Euro screw 6,3x11 mm...
- Page 4 PU843,030-040 FIG. (Suspension list) (Support ) (Suspension list) NB!!! BP21XXX Alu profil (Side) (Base-top) FIG. (Back panel) 02-09-2018 0b...
- Page 5 PU843,030-040 FIG. Screw flh 3,5x45 mm 4 pcs (Side) FIG. Screw flh 3,5x45 mm 4 pcs 02-09-2018 0b...
- Page 6 PU843,030-040 FIG. Euroscrew 4,2x9,5 4 pcs BP01907 R 48,5x30 mm 1 pcs Always use # 2 in right side Euroscrew 4,2x9,5 BP01907 L 48,5x30 mm 1 pcs BP21XXX Alu profil Always use # 1 in left side FIG. NB: Always use # 1 in Left side Euro screw 5,8x15...
- Page 7 PU843,030-040 FIG. ID20102 / ID20103 Trash system 02-09-2018 0b...
