Summary of Contents for Lilliput PC-702

  • Page 1 Embedded Computer User Manual...
  • Page 2 Safety Maintenance: Please maintain your system properly to make sure its service life and reduce the damage risk.  It should be avoid the humidity and extreme temperature when being used.  Avoid prolonged exposure of the unit to direct sunlight or strong ultraviolet light.
  • Page 3: Table Of Contents

    Content 1. Product Description ......................3 1.1 Brief Introduction ......................3 1.2 Optional Functions ..................... 3 1.3 Basic Parameters ....................... 3 1.4 3G/4G Support Parameter&Switch ................5 2. Structure Function Explanation..................6 3. Extened Cable Definition ....................7 3-1 Serial Port ........................ 8 3-2 GPIO Interface ......................
  • Page 4: Product Description

    Production Description 1.1 Brief Introduction  7" 16:10 multi point capacitive touch screen,1280x800 physical resolution.  Intel Atom Z8350 1.44G , 2G DRAM , 32G Emmc, Intel HD Graphic 400;  Windows 10 32-bit;  RS232x4/GPIO(4 input,6 output)/LANx2/USB2.0/USB3.0/HDMI interface;  Micro SD(TF)card storage,mini SIM card slot. 1.2 Optional Functions ...
  • Page 5 GPU: Intel HD Graphic 400 OS:Windows 10 32-bit (Optional) SIM card 1.8V/2.95V,mini SIM TF card 1.8V/2.95V, up to 64G USB host 2.0×2 (support USB 3.0) Input×4, Output×6(See section "3. Extended Interfaces GPIO Cable Definition" for details.) HDMI output HDMIv1.4 100M×2 Serial Port COM3 COM4 COM5 COM6 Ear Jack...
  • Page 6: 4G Support Parameter&Switch

    1.4 3G / 4G Support Parameter & Switch FDD LTE: Band 1/Band 3/ Band 8 TDD LTE: Band 38/Band 39 /Band 40/Band Version 1 DC-HSPA+/HSPA+/HSPA/UMTS: Band China/India 1/Band 5/Band 8/Band 9 TD-SCDMA: Band 34/Band 39 GSM/GPRS/EDGE: 1800 /900 Band (Different FDD LTE: Band 1/Band 2 /Band 3/Band 4 versions support /Band 5 /Band 7/Band 8/Band 20...
  • Page 7: Structure Function Explanation

    Structure Function Explanation Power indicator Reset & burn button User-definable button1 (F1) User-definable button2 (F2) Power on/off button 1. Mini SIM card slot. 2. Micro SD slot 3. IOIO 1: (RS232 standard interface, connecting with DB9 standard cable to convert to 3×RS232 ports). IOIO 2: (RS232 standard interface, connecting with DB9 optional cable to...
  • Page 8: Extened Cable Definition

    convert to 1×RS232, 1×RS422 and 1×RS485 ports). 4. GPIO (For extended cable definition, please refer to "3. Extended Cable Definition"). 5. HDMI output. 6. USB Host×2. 7. 100M LAN. 8. 100M LAN, POE function for optional. 9. Ear jack. 10. Power interface. Extended Cable Definition...
  • Page 9 Item Definition Com 3 RS232 COM3 Com 4 RS232 COM4 Com 5 RS232 COM5 COM 6 RS232 COM6 RS422 Red A White Z COM5 Black B Green Y RS485 Red Positive Pole COM6 Black Negative Pole Note: RS232 and RS422 are alternative for COM5. RS232 and RS485 are alternative for COM6.
  • Page 10: Serial Port

    3-1 Serial Port The COM port serial will change bases on the installation order of the 3G/4G device and the FTDI USB serial port device, which affect the serial port access of RS485/RS422. The following figure shows the serial port identifier after installing the 3G/4G driver first and then installing the USB serial port driver.
  • Page 12: Gpio Interface

    3-2 GPIO Interface 1. GPIO interface as shown below. (GPIO0-GPIO3 is input port,GPIO4-GPIO9 is output port.) For the implement and assess method, please see "GPIOTest demo " in CD coming with the device for details.
  • Page 13: Memory Card Instruction

    Memory Card Instructions  The memory card and the card slot on the device are precision electronic components. Please align to the position accurately when inserting the memory card into the card slot to avoid of damage. Please slightly push the upper edge of the card to loosen it when removing the memory card, then pull it out.
  • Page 14  Network settings: Network Connections shown as Figure2. Make sure the MAC address shown on the screen should be match with the one labeled on the rear of device as the device has two LAN ports. Figure 2  Wi-Fi connection shown as Figure 3 Figure 3...
  • Page 15  Application of SIM Card (Please note the device should be restarted after SIM card inserted) shown as Figure 4. Figure 4  Browser shown as Figure 5. Figure 5  Application of Bluetooth:Bluetooth Manager shown as Figure 6.
  • Page 16 Figure 6  Multimedia shown as Figure 7 Figure 7...
  • Page 17: Mounting Methods

     Brightness settings shown as Figure 8. Figure 8 Mounting Methods VESA 75mm rail slot Embedded mount...
  • Page 18: Accessories

    Accessories Standard Accessories: 1. DC12V adapter-----------------------------------------------------------------1piece 2. GPIO cable----------------------------------------------------------------------1piece 3. DB9 cable(RS232x3)------------------------------------------------------1piece 4. CD drive--------------------------------------------------------------------------1piece 5. Fixed screw--------------------------------------------------------------------- 4pieces 6. User Manual---------------------------------------------------------------------1copy Optional accessories: 1. DB9 cable(RS232x1,RS485,RS422)------------------------------1piece 2. Micro TF Card-------------------------------------------------------------------1piece 3. 75mm VESA rail slot-----------------------------------------------------------1piece...
  • Page 19: Trouble Shooting

    Trouble Shootings Power Problem Cannot boot up Wrong cable connection Connect Extended cable with device first, and connect the AC end of DC adapter with DC input port of Extended cable, then the other end of DC adapter connect with power plug socket. Bad connection Check every connection and socket of power source.
